Arduino MKR NB 1500 NB-IoT Development Board
The Arduino MKR NB 1500 is an IoT development board featuring the Microchip Technology SAMD21 Cortex-M0+ MCU and a U-Blox SARA-R410M-02B NB-IoT modem, enabling reliable cellular connectivity with low power consumption for remote applications.
Features
- Integrates Microchip Technology SAMD21 Cortex-M0+ 32-bit low-power ARM MCU.
- Features U-Blox SARA-R410M-02B modem for NB-IoT cellular connectivity.
- Equipped with a microSIM slot and uFL connector for external GSM antenna.
- Standard Arduino MKR form factor with a wide range of I/O interfaces.
- Optimized for low power consumption in remote IoT deployments.
Out of stock
The Official Arduino MKR NB 1500 is an Internet of Things (IoT) development board engineered for wireless connectivity based on narrowband (NB) IoT standards. This advanced communications technology leverages existing LTE cellular networks to deliver significantly faster data rates compared to alternative IoT networks like LoRa and Sigfox, all while maintaining a minimal impact on battery life. It also boasts much faster wake-up and connection times compared to typical GSM or 3G cellular connectivity, leading to substantial power savings crucial for remote deployments.
Powered by a Microchip Technology Technology SAMD21 Cortex-M0+ 32-bit low-power ARM MCU, the MKR NB 1500 adheres to the Official Arduino MKR footprint, ensuring broad compatibility with Arduino Uno, Mega, and existing MKR boards. The board operates at 3.3V and offers a rich set of interfaces, including I2S, I2C, UART, and SPI. It provides 22 digital I/O pins (12 of which support PWM) and seven analog input pins, making it versatile for diverse sensor and actuator integrations.
Additional Information
| Weight | 0.023 kg |
|---|---|
| Dimensions | 6.764 × 2.5 cm |
