Generic 50cm SMA Female to IPEX1 RF Cable RG1.13
This 50cm RG1.13 RF pigtail cable provides a reliable interface conversion from a panel-mount SMA female connector to an IPEX1 (u.FL) socket, enabling antenna connections for embedded wireless modules in cellular, GNSS, Wi-Fi, and LoRa applications.
Features
- Provides a critical interface bridge between panel-mount SMA antennas and compact IPEX1/u.FL connectors on embedded modules.
- RG1.13 coaxial cable ensures stable signal transmission across a broad 0-6GHz frequency range for 5G, 4G, Wi-Fi, and GNSS.
- 50cm length offers flexible routing for optimal antenna placement within device enclosures or prototypes.
- SMA female connector with 13mm thread length is designed for secure panel mounting on chassis or enclosures.
- Essential accessory for developers integrating cellular (SIM7600, SIM7000), Wi-Fi/Bluetooth (ESP32), or LoRa (RAK3172) modules requiring external antennas.
Out of stock
This SMA Female to IPEX1 RF cable is a fundamental interconnect for IoT hardware development, solving the common form-factor mismatch between external antennas and compact module sockets. The RG1.13 coaxial construction maintains 50-ohm impedance, supporting frequencies from DC up to 6GHz with minimal signal loss, making it suitable for high-speed 4G/5G cellular data, precise GNSS positioning, and 2.4/5GHz Wi-Fi bands.
The cable features a robust SMA female connector designed for through-hole panel mounting, providing a secure and grounded interface for standard SMA male antenna leads. The opposite end terminates in an IPEX1 (also known as u.FL or MHF) plug, which mates with the ultra-small, surface-mount connectors found on most modern wireless communication modules. This setup is critical for achieving maximum RF performance and range in space-constrained designs.
Additional Information
| Weight | 0.006 kg |
|---|---|
| Dimensions | 7 × 10 × 1 cm |
