Arducam B0273 12MP Motorized Focus Camera for Jetson Nano/Orin
The Arducam B0273 is a 12MP motorized focus camera module designed for NVIDIA Jetson platforms, including Nano, Xavier NX, and Orin NX/AGX Orin. It features software-controlled autofocus via OpenCV or keyboard commands, eliminating manual lens adjustment for streamlined computer vision and AI development.
Features
- 12MP High-Resolution Sensor – Captures detailed 4056 x 3040 pixel images for advanced computer vision, object detection, and AI inference tasks on Jetson.
- Software-Controlled Motorized Focus – Remotely adjust focus via OpenCV or keyboard commands, enabling dynamic focus changes for applications like automated inspection.
- Direct Jetson Platform Compatibility – Plug-and-play with Jetson Nano, Xavier NX, Orin NX, and AGX Orin via included flex cables; no hardware modifications required.
- M12 Lens Mount & 75° FOV – Standard M12 mount with a 75° horizontal field of view and integrated IR-cut filter for clear visible-light imaging.
Out of stock
The Arducam B0273 camera module integrates a high-resolution 12MP (1/2.3-inch) sensor with a built-in focusing motor, engineered specifically for NVIDIA’s Jetson edge AI ecosystem. This design replaces the traditional manual focus lens screw mechanism with precise software control, allowing developers to programmatically adjust focus through OpenCV scripts or simple keyboard inputs. This capability is critical for dynamic vision systems where subject distance varies, such as in robotic navigation or automated quality control stations.
Built for seamless integration, the module connects directly to Jetson developer kits via the supplied 15-pin to 22-pin flex ribbon cables, leveraging the native CSI-2 interface. It maintains full compatibility with Jetson’s camera software stack, including GStreamer and NVIDIA’s deep learning vision pipelines. The compact 38x38mm form factor and M12 lens mount make it suitable for embedded vision applications where space is constrained but high-fidelity image data is required for TensorRT-accelerated models.
Additional Information
| Weight | 0.025 kg |
|---|---|
| Dimensions | 3.8 × 3.8 cm |
