Waveshare CAN Bus Module (B) for Raspberry Pi Pico
Waveshare CAN Bus Module (B) for Raspberry Pi Pico - Image 2
Waveshare CAN Bus Module (B) for Raspberry Pi Pico - Image 3
SKU: SBCD-1375
📋 GST Invoice Available

Waveshare CAN Bus Module (B) for Raspberry Pi Pico

₹1,579.00 (Inclusive of all taxes)
Out of Stock

The Waveshare CAN Bus Module (B) provides robust long-range communication capabilities for your Raspberry Pi Pico projects. Integrating the MCP2515 CAN controller and SIT65HVD230DR transceiver, it enables reliable data exchange over the SPI interface for industrial and automotive applications.

Features

  • Designed for Raspberry Pi Pico, ensuring seamless integration and header compatibility.
  • Utilizes MCP2515 CAN controller and SIT65HVD230DR transceiver for reliable CAN communication.
  • Enables long-range, high-speed data exchange via the SPI bus.
  • Provides comprehensive online development resources including C/C++ and MicroPython examples.

Out of stock

Description

The Waveshare CAN Bus Module (B) empowers the Raspberry Pi Pico with essential Controller Area Network (CAN) communication functionality. Tailored specifically for the Pico’s standard header, this module integrates the widely used MCP2515 CAN controller and the SIT65HVD230DR CAN transceiver, forming a robust solution for embedded systems requiring resilient serial communication over extended distances.

Operating through the SPI interface, the module facilitates data transfer rates from 5K to 1000Kbps, making it suitable for a diverse range of applications, including industrial control, automotive diagnostics, and distributed sensor networks. Its design prioritizes ease of use, offering developers a straightforward path to implement CAN protocols on their Pico-based projects with provided C/C++ and MicroPython examples.

Key Features

  • Standard Raspberry Pi Pico header ensures direct compatibility with Pico series boards.
  • Incorporates MCP2515 standalone CAN controller for efficient CAN protocol handling.
  • Equipped with SIT65HVD230DR CAN transceiver for robust physical layer communication.
  • Communicates via high-speed SPI bus, simplifying integration with the Pico.
  • Supports a wide baud rate range from 5K to 1000Kbps for flexible application requirements.
  • Operating voltage range of 3.3V to 5V, compatible with common microcontroller power rails.
  • Comes with online development resources and a detailed manual, including code examples.

Applications

  • Industrial control and automation systems requiring robust fieldbus communication.
  • Automotive diagnostics and data logging for vehicles.
  • Distributed embedded systems and sensor networks.
  • Robotics communication and control within harsh environments.
  • Building automation and smart home integration using CAN bus.

Technical Specifications

CAN ControllerMCP2515
CAN TransceiverSIT65HVD230DR
Communication BusSPI
Operating Voltage3.3V~5V
Baud Rate5K~1000Kbps
CompatibilityRaspberry Pi Pico

Frequently Asked Questions

What is the primary function of the Waveshare CAN Bus Module (B)?

This module enables the Raspberry Pi Pico to communicate over a Controller Area Network (CAN) bus. It is ideal for applications requiring robust, long-distance data exchange, such as industrial automation, automotive diagnostics, and distributed embedded systems, using the SPI interface.

Which CAN controller and transceiver does this module use?

The module integrates the Microchip Technology MCP2515 standalone CAN controller, which handles the CAN protocol, and the STMicroelectronics SIT65HVD230DR CAN transceiver, responsible for the physical layer communication. This combination ensures reliable and efficient data transmission.

What programming languages and development resources are supported for the module?

Waveshare provides comprehensive online development resources and a manual for this module. These resources typically include example code and libraries for both Raspberry Pi Pico C/C++ SDK and MicroPython, facilitating rapid development and integration into your projects.

What are the supported operating voltage and communication baud rates?

The Waveshare CAN Bus Module (B) operates with a flexible voltage supply between 3.3V and 5V, making it compatible with various Pico setups. It supports a wide range of baud rates from 5K to 1000Kbps, allowing configuration for different network speeds and application needs.

Package Includes

  • 1 x Waveshare CAN bus Module (B) for Raspberry Pi Pico

Additional Information

Weight 0.006 kg
Dimensions 11 × 8 × 1 cm
