SKU: DRFC-3407
📋 GST Invoice Available

SIYI MK15 Mini Agriculture Drone Smart Controller with HD FPV Display Combo

₹68,089.00 (Inclusive of all taxes)
Out of Stock

The SIYI MK15 Mini Agriculture Drone Smart Controller is a handheld ground control station featuring a 5.5-inch HD touchscreen display and integrated 1080p digital FPV system for real-time monitoring and control of agricultural UAVs, supporting automated flight paths and field mapping.

Features

  • 5.5-inch high-brightness HD LCD touchscreen display for clear outdoor viewing.
  • Integrated 1080p dual HD digital image transmission with up to 3.5 km range.
  • Smart agriculture software suite for crop monitoring, spraying, and field mapping.
  • Built-in 10200mAh 2S Li-ion battery for extended field operation.
  • Rugged, portable design with IP67-rated camera and weather-resistant construction.

Out of stock

Description

The SIYI MK15 Smart Controller is engineered as a dedicated ground control station for precision agriculture drone operations. It consolidates flight control, high-definition FPV, and mission planning into a single, portable handheld unit. The system provides a low-latency, 1080p digital video downlink from the drone’s camera, enabling operators to conduct detailed real-time inspections and manage automated application tasks directly from the field.

Built around a powerful internal processor and a high-capacity battery, the controller supports full-featured navigation with GPS positioning, real-time telemetry overlay, and programmable flight paths. Its ruggedized chassis and ergonomic form factor are designed to withstand the demands of daily agricultural use, ensuring reliable performance in various environmental conditions.

Key Features

  • High-Definition FPV System: 1080p dual digital transmission with 180ms latency for real-time, crystal-clear aerial imagery.
  • Agricultural Mission Software: Integrated smart functions for precise crop monitoring, variable-rate application mapping, and automated flight pattern execution.
  • Long-Range Connectivity: Supports transmission ranges up to 3.5 km with optional high-gain antennas for extended field coverage.
  • High-Capacity Power System: Integrated 10200mAh 2S Li-ion battery (75.48 Wh) powers the controller for extended operational sessions.
  • Ruggedized & Portable Design: Compact, handheld form factor with IP67-rated components built to endure dust, moisture, and field use.
  • Comprehensive Data Overlay: On-screen display of critical flight telemetry including altitude, speed, battery status, and GPS coordinates.
  • Versatile Antenna Support: Compatible with omni-directional (5 dBi) and optional long-range (11 dBi) antennas for optimized signal strength.

Applications

  • Precision agriculture drone operations for crop health monitoring and scouting.
  • Ground control station for automated pesticide or fertilizer spraying UAVs.
  • Field mapping and surveying missions requiring real-time HD video feedback.
  • Livestock and irrigation system inspection using long-range FPV capabilities.

Technical Specifications

Item TypeController
Display5.5-Inch High Definition LCD Touchscreen
Battery10200 mAh, 7.4V 2S Li-ion, 75.48 Wh
Image Transmission1080p Dual HD Digital
Transmission Range3.5 km
Latency180 ms
Camera RatingIP67
Antenna Gain (Standard)Omni Antenna: 5 dBi
Field of View (FOV)120°
Input Voltage12 V
Power ConsumptionLED OFF: 3 W, LED ON: 8 W
Image Sensor1/2.9 Inch, 2 MP

Frequently Asked Questions

What is the transmission range and video quality of the SIYI MK15 controller?

The SIYI MK15 controller features a 1080p dual HD digital image transmission system with a maximum operational range of 3.5 kilometers. Video latency is rated at 180ms, providing a clear, real-time FPV feed suitable for detailed agricultural inspection and navigation.

What type of battery does the controller have, and how long does it last?

The controller is powered by an integrated 10200mAh 2S Li-ion battery pack (7.4V, 75.48Wh). Actual runtime depends on display brightness and transmission power settings, but the high capacity is designed to support extended fieldwork sessions typical of agricultural drone operations.

Is the SIYI MK15 compatible with all agricultural drones?

No, the MK15 is designed as a dedicated smart controller for SIYI's ecosystem and compatible UAV platforms that support its specific digital transmission protocol and command set. It is essential to verify compatibility with your specific drone model before purchase.

What smart agriculture functions does the controller software include?

The integrated software supports functions crucial for precision agriculture, including automated flight path planning for field mapping, waypoint navigation for systematic crop scouting, and tools for monitoring spray coverage or creating variable-rate application maps based on real-time imagery.

Package Includes

  • 1 x SIYI MK15 Mini Agriculture Drone Smart Controller with HD FPV Display Combo

Additional Information

Weight 1.598 kg
Dimensions 24 × 21 × 12 cm
