Seeed Studio Studio Grove Luminance Sensor Module - APDS-9002 Analog Output
The Seeed Studio Studio Grove Luminance Sensor is an analog ambient light sensing module built around the APDS-9002 photosensor, providing a linear voltage output proportional to light intensity. It is designed for easy integration with Arduino, Raspberry Pi, and other 3.3V/5V microcontroller platforms via the Grove connector system.
Features
- Analog output ambient light sensor based on the APDS-9002 photosensor.
- Wide operating voltage range from 2.4V to 5.5V for compatibility with 3.3V and 5V logic systems.
- Linear voltage output range of 0V to 2.3V directly proportional to detected light intensity.
- Standard Grove 4-pin connector for plug-and-play connectivity with Seeed Studio Studio ecosystem boards.
- Compact and lightweight PCB module with pre-mounted mounting holes for secure installation.
Out of stock
The Grove Luminance Sensor utilizes the APDS-9002, a high-performance analog ambient light photosensor. It converts incident light intensity into a corresponding analog voltage signal, offering a simple and direct method for light level monitoring without the need for complex digital communication protocols.
The module’s output is linear across its specified range, simplifying calibration and scaling in software. Its wide supply voltage range ensures stable operation across common development board voltages, making it a versatile component for environmental sensing, automatic brightness control, and light-triggered systems.
Additional Information
| Weight | 0.008 kg |
|---|---|
| Dimensions | 13 × 9 cm |
