Omron E2K-C25MF1 Capacitive Proximity Sensor, 25mm Range, PNP NO Output, 12-24VDC, IP66
The Omron E2K-C25MF1 is a capacitive proximity sensor with a 25mm sensing range, designed for industrial automation. It operates on 12-24VDC with a PNP normally-open output, features IP66 protection, and is compatible with PLCs and standard 3-wire DC control systems.
Features
- Capacitive sensing technology detects both conductive and non-conductive materials.
- 25mm nominal sensing distance with adjustable sensitivity for precise detection.
- PNP (sourcing) normally-open output with a 200mA maximum switching capacity.
- Robust IP66-rated ABS resin housing for reliable operation in dusty or wet industrial environments.
- Wide 12-24VDC operating voltage range with built-in reverse polarity and surge protection.
Out of stock
The Omron E2K-C25MF1 is an unshielded, cylindrical capacitive proximity sensor engineered for versatile object detection in industrial settings. Its capacitive sensing principle allows it to detect a wide range of materials, including metals, plastics, liquids, and powders, making it suitable for applications beyond standard inductive sensing.
Featuring a 34mm diameter sensing face, this sensor provides a reliable 25mm nominal detection distance. It is built with a heat-resistant ABS resin housing and achieves an IP66 rating, ensuring protection against dust ingress and powerful water jets for durability in challenging environments. The integrated protective circuitry safeguards against wiring errors and electrical noise.
Additional Information
| Weight | 0.236 kg |
|---|---|
| Dimensions | 11 × 11 × 7 cm |
