MAD Components Components BSC2207.5 V1.0 2207.5 Brushless Motor 1750KV 6S
The MAD Components Components BSC2207.5 V1.0 is a 2207.5-size brushless motor rated for 1750KV and 6S LiPo operation, engineered for high-performance FPV freestyle and racing drones requiring a balance of power and smoothness.
Features
- 2207.5 stator size (27mm diameter) optimized for 5-inch and 6-inch propellers on 4S-6S LiPo.
- 1750KV rating delivers high torque and RPM for aggressive freestyle and racing maneuvers.
- 12N14P (12-pole, 14-slot) magnetic configuration for smooth operation and reduced cogging.
- Factory rotor balance ≤5mg ensures minimal vibration for clean FPV video footage.
- 4mm shaft diameter and M5 mounting pattern for standard FPV frame compatibility.
Out of stock
The MAD Components BSC2207.5 V1.0 motor utilizes a 2207.5 stator (27mm diameter x 32.3mm height) to provide a robust power-to-weight ratio suitable for demanding 5-inch and 6-inch FPV quadcopter builds. Its 1750KV winding is optimized for 4S to 6S battery packs, offering a wide throttle response ideal for both explosive power and efficient cruising.
Constructed with a 12N14P design, the motor achieves smoother rotation and enhanced low-end torque, reducing cogging for precise control. The high-quality bearings and rigid bell housing contribute to its durability, handling the high rotational forces encountered in freestyle and racing applications. The included 150mm 20AWG silicone wires allow for flexible installation in tight frame layouts.
Additional Information
| Weight | 0.05 kg |
|---|---|
| Dimensions | 6 × 6 × 4 cm |
