MAD Components Components BSC 2306 1750KV 6S Brushless Motor
The MAD Components Components BSC 2306 is a 1750KV brushless motor engineered for high-performance 6S LiPo (22.2V) FPV drone systems, delivering high torque and efficient power for aggressive freestyle and racing applications.
Features
- 1750KV rating optimized for 6S LiPo (22.2V) power systems
- 2306 stator size (23mm diameter, 6mm height) for balanced power-to-weight ratio
- 12N14P pole configuration for smooth, efficient torque delivery
- High-precision rotor balancing ensures minimal vibration for stable flight
- M5 propeller nut and 16mm M3 mounting hole pattern for secure installation
Out of stock
The MAD Components Components BSC 2306 1750KV motor is designed for pilots seeking robust performance on 6S LiPo systems. Its 12N14P electromagnetic configuration provides a smooth power curve with high torque output, enabling precise control during aggressive maneuvers and high-speed flight.
Constructed with durable materials and high-precision balancing, this motor minimizes operational vibration, which contributes to smoother video footage and reduced stress on airframe components. The 2306 stator size offers an optimal blend of power and efficiency for 5-inch and 6-inch FPV quadcopter builds.
Additional Information
| Weight | 0.047 kg |
|---|---|
| Dimensions | 6 × 6 × 4 cm |
