Linpowave V300 4D mmWave Radar for ADAS - RS-422, 300m Range
The Linpowave V300 is a 77-81 GHz 4D millimeter-wave radar module designed for advanced driver-assistance systems (ADAS) and industrial automation. It provides precise distance, angle, and velocity tracking of multiple objects via RS-422/CAN/UART interfaces, operating reliably from -40°C to +85°C.
Features
- 77-81 GHz 4D mmWave Radar with 0.5-200m (300m max) detection range.
- 4D object tracking (X, Y, Z, Vx, Vy, Vz) with ±55 m/s velocity detection.
- Multi-mode operation (USRR, MRR, LRR) with a 20Hz real-time data refresh rate.
- All-weather operation resistant to fog, rain, snow, and dust.
- Compact, low-power design (<2W average) with RS-422, CAN, and UART communication.
Out of stock
The Linpowave V300 leverages advanced 4D millimeter-wave radar technology to deliver high-resolution environmental perception for autonomous and safety-critical applications. Its sophisticated algorithms process reflected signals to generate precise 4D point clouds, enabling accurate tracking of object position and velocity vectors in real-time.
Engineered for harsh environments, the sensor maintains stable performance across a wide temperature range from -40°C to +85°C, with inherent immunity to adverse weather conditions like fog, dust, rain, and snow. The module’s compact form factor and efficient power profile facilitate seamless integration into vehicle ECUs, robotics platforms, and industrial automation systems.
Additional Information
| Weight | 0.114 kg |
|---|---|
| Dimensions | 9.5 × 8.5 cm |
