Honeywell SS566AT Bipolar Hall Effect Magnetic Sensor - SOT-89-3 SMD
The Honeywell SS566AT is a bipolar digital Hall-effect sensor IC in an SOT-89-3 SMD package, designed for precise magnetic field detection with an operating point range of 100 G to 180 G. It operates from a 3 Vdc supply, making it suitable for low-voltage, energy-efficient designs and integration into automated PCB assemblies.
Features
- Bipolar digital Hall-effect sensor with 100 G to 180 G operating point range.
- Compact SOT-89-3 surface-mount (SMD/SMT) package for automated PCB assembly.
- Low-voltage operation from 3 Vdc, with a typical supply current of 8.7 mA.
- Wide operating temperature range from -40°C to 150°C for stable performance.
- Maximum output current of 20 mA for direct interfacing with logic circuits.
Out of stock
The SS566AT from Honeywell is a versatile, board-mount digital Hall-effect sensor IC that responds to the magnetic field from a permanent magnet or electromagnet. Its bipolar design requires both a south and north pole to operate, making it ideal for precise position sensing in motion control applications. The device provides a digital output signal that switches in response to the applied magnetic flux density within its specified range.
Engineered for reliability in harsh environments, the sensor maintains stable operation across an extended industrial temperature range from -40°C to 150°C. Its 3 Vdc capability supports modern low-power designs, promoting system-level energy efficiency while the SOT-89-3 package enables compact, cost-effective assembly in space-constrained applications.
Additional Information
| Weight | 0.11 kg |
|---|---|
| Dimensions | 8 × 6 × 3 cm |
