Grow GM861 Barcode Scanner Module - UART/USB Interface, CMOS Sensor
The Grow GM861 is a compact CMOS-based barcode scanner module offering UART and USB interfaces for seamless integration into embedded systems, POS terminals, and industrial automation equipment. It provides reliable reading of both 1D and 2D codes, including QR codes, within a 5-30cm range.
Features
- Dual UART and USB 2.0 communication interfaces for flexible system integration.
- High-resolution 640×480 CMOS sensor for accurate 1D and 2D barcode/QR code reading.
- Wide reading distance range from 5cm to 30cm with a 360° roll scan angle.
- Low-power operation at 3.3V DC with a maximum current draw of 70mA.
- Compact, lightweight design ideal for space-constrained embedded and portable applications.
Out of stock
The Grow GM861 barcode scanner module utilizes a high-performance CMOS imaging sensor to capture and decode a wide array of 1D and 2D symbologies. Its 640×480 pixel resolution ensures reliable reading even on small or low-contrast codes. The module outputs decoded data via a selectable UART (TTL-level) or USB 2.0 interface, making it compatible with microcontrollers like Arduino, Raspberry Pi, and industrial PLCs.
Engineered for continuous operation in commercial and industrial environments, the GM861 features a green LED indicator for positive read confirmation. Its optical system is optimized for a reading distance of 5 to 30 centimeters, with generous pitch and yaw tolerances to accommodate varied mounting angles and product orientations on assembly lines or point-of-sale systems.
Additional Information
| Weight | 0.05 kg |
|---|---|
| Dimensions | 5 × 5 × 5 cm |
