Grow GM67 Barcode Scanner Module - USB2.0 & UART Interface
The Grow GM67 is a high-resolution CMOS barcode scanner module supporting comprehensive 1D and 2D symbologies, including QR Code and Data Matrix. It interfaces via USB2.0 or UART for seamless integration into embedded systems, POS terminals, and industrial automation equipment.
Features
- High-resolution 640×480 CMOS sensor with 5mil scanning capability
- Dual interface support: USB2.0 (HID/CDC) and asynchronous UART (TTL)
- Wide reading distance range from 25mm to 250mm
- Comprehensive 1D/2D barcode support including EAN, UPC, Code 39/93/128, QR Code, PDF417, and Data Matrix
- Compact embedded module design for OEM integration
Out of stock
The GM67 barcode scanner module utilizes a 640*480 pixel CMOS image sensor to capture and decode a wide array of 1D and 2D barcodes with a high resolution of 5mil. Its imaging-based scanning provides reliable performance on both printed labels and direct part marks within its 25-250mm working range.
Engineered for embedded applications, the module offers flexible connectivity through its USB2.0 (supporting HID keyboard emulation or virtual COM port) and UART TTL serial interfaces. Operating from a standard 5V DC supply, it delivers efficient and stable performance for integration into point-of-sale systems, inventory management kiosks, and automated industrial equipment.
Additional Information
| Weight | 0.2 kg |
|---|---|
| Dimensions | 8 × 10 × 3 cm |
