Generic Y3 Strain Gauge Bending Sensor Weighing Amplifier Module Version B
The Y3 Strain Gauge Bending Sensor Module (Version B) is a compact load measurement solution integrating a high-sensitivity strain gauge load cell with a built-in amplifier. It provides a stable analog voltage output for direct interfacing with 5V microcontrollers like Arduino and Raspberry Pi, ideal for precision weighing and force detection applications.
Features
- Integrated high-gain amplifier for stable analog voltage signal output
- 5V DC operation compatible with Arduino, Raspberry Pi, and other 5V logic systems
- High-sensitivity strain gauge load cell for precise force and weight measurement
- Compact PCB design (approx. 35mm x 17mm) for easy integration into projects
- Tool-free installation and durable bending beam structure for reliable performance
Out of stock
The Y3 Strain Gauge Bending Sensor Module (Version B) utilizes a precision strain gauge bonded to a bending beam structure. When force is applied, the resulting strain alters the gauge’s electrical resistance. The integrated high-gain instrumentation amplifier conditions this small signal, providing a robust, linear analog voltage output proportional to the applied load.
Designed for 5V DC systems, the module simplifies interfacing by eliminating the need for external signal conditioning circuits. Its compact form factor and straightforward analog output make it suitable for integration into electronic weighing scales, force feedback systems, and industrial process monitoring where reliable, amplified load cell signals are required.
Additional Information
| Weight | 0.003 kg |
|---|---|
| Dimensions | 3.5 × 1.7 cm |
