Geekworm X1300-A2 I2S HDMI Audio Board for X1300/X630
The Geekworm X1300-A2 is an I2S audio accessory board designed for X1300 and X630 shields, enabling seamless HDMI audio capture for your Raspberry Pi setup. It offers straightforward installation without soldering, making it ideal for integrating high-quality audio into embedded systems.
Features
- Enables HDMI audio capture via I2S interface.
- No soldering required for easy, rapid installation.
- Compact, stackable design reserves space for CPU heatsink.
- Advanced features including HDMI cable detection and interrupt capabilities.
- Compatible with Geekworm X1300 (Raspberry Pi 5) and X630 (Raspberry Pi 4B/3B+).
Out of stock
The Geekworm X1300-A2 serves as a dedicated I2S audio accessory board, purpose-built to augment the capabilities of the Geekworm X1300 and X630 shields. This module facilitates high-fidelity HDMI audio capture, converting the incoming digital audio stream into the I2S format for direct processing by the host system. Its design prioritizes ease of integration, eliminating the need for complex soldering during setup.
Functionally, the X1300-A2 extends the audio input options for Raspberry Pi-based projects, making it suitable for applications requiring robust audio acquisition from HDMI sources. It features built-in mechanisms for HDMI cable detection and interrupt handling, ensuring reliable operation. The board’s compact footprint allows for stacking beneath other HATs, preserving valuable space in embedded designs while maintaining access to the Raspberry Pi’s 40-pin GPIO header.
Additional Information
| Weight | 0.038 kg |
|---|---|
| Dimensions | 9 × 9 × 4 cm |
