FrSky TDR6 Dual-Band Receiver (2.4GHz & 900MHz)
The FrSky TDR6 is a dual-band receiver operating simultaneously on 2.4GHz and 900MHz frequencies, designed for the TANDEM protocol. It provides low-latency control, extended range up to 100KM, and robust anti-interference performance, featuring 6 PWM outputs, SBUS, and FBUS/S.Port connectivity for advanced telemetry integration.
Features
- Simultaneous dual-band TD mode operation on 2.4GHz & 900MHz frequencies.
- Dual-band antenna design for multi-directional signal coverage and high reliability.
- Long-range control capability, rated for distances up to 50KM – 100KM.
- 6 PWM channel outputs with SBUS Out and configurable FBUS/S.Port telemetry port.
- Integrated Black Box function for logging power and signal telemetry data.
Out of stock
The FrSky TDR6 Dual-Band Receiver leverages the TANDEM protocol to concurrently utilize 2.4GHz and 900MHz bands, creating a redundant communication link that significantly enhances signal reliability and resistance to interference. This dual-band architecture ensures consistent control link integrity, even in challenging RF environments, making it suitable for long-range FPV and UAV applications where signal dropout is unacceptable.
Engineered for integration, the TDR6 provides 6 standard PWM outputs alongside digital serial interfaces. Its configurable S.Port can be set to the FBUS protocol, enabling seamless daisy-chaining with a wide array of FrSky telemetry peripherals such as Neuron ESCs and advanced sensors. The built-in Black Box module records critical telemetry parameters, offering valuable data for post-flight analysis of signal health and system performance.
Additional Information
| Weight | 0.0115 kg |
|---|---|
| Dimensions | 4.75 × 2.04 × 1.09 cm |
