Figaro Engineering TGS5141-P00 Carbon Monoxide Sensor - 0-5000ppm, Battery Operable
The Figaro Engineering TGS5141-P00 is an ultra-compact, battery-operable electrochemical carbon monoxide sensor designed for portable and residential safety applications. It provides a linear output current proportional to CO concentration from 0 to 5000 ppm, making it suitable for integration into CO detectors and multi-sensor fire alarms.
Features
- Electrochemical sensing element for carbon monoxide (CO) detection
- Ultra-compact design, approximately 10% the size of previous models
- Linear output current: 1.2 to 3.2 nA/ppm in CO over 0-5000 ppm range
- Battery-operable with no external water reservoir required
- High repeatability and selectivity for reliable CO monitoring
Out of stock
The TGS5141-P00 utilizes Figaro Engineering’s advanced electrochemical sensing technology with a unique solid electrolyte, eliminating the need for a traditional water reservoir. This innovation drastically reduces the sensor’s footprint and power requirements, enabling its use in battery-powered, space-constrained designs. The sensor exhibits a linear relationship between gas concentration and output signal, simplifying calibration and integration into monitoring systems.
Designed for robust performance, the sensor operates across a wide humidity range from 10% to 95% RH (non-condensing) and a temperature range of -20°C to +60°C intermittently. Each unit features individual barcoded calibration data, allowing OEMs to implement sensor-specific compensation and tracking without costly gas calibration procedures, enhancing production efficiency and traceability.
Additional Information
| Weight | 0.03 kg |
|---|---|
| Dimensions | 7 × 9 × 2 cm |
