Benewake TFMini Micro LiDAR Distance Sensor 0.3–12m - UART Interface
The Benewake TFMini is a compact, low-power Time-of-Flight (ToF) LiDAR distance sensor module offering 0.3M to 12m range detection via UART serial communication. It is designed for integration with drones, UAVs, robots, and industrial equipment requiring high-speed, non-contact ranging.
Features
- Time-of-Flight (ToF) LiDAR principle with 850nm infrared LED for eye-safe operation.
- 0.3M to 12m measurement range with accuracy of 1% (<6m) and 2% (6-12m).
- UART serial interface for easy integration with microcontrollers (Arduino, Raspberry Pi, Pixhawk).
- Low power consumption (0.12W) and compact dimensions (42 x 15 x 16 mm).
- 100Hz update rate and 5mm resolution for high-speed, precise distance tracking.
Out of stock
The Benewake TFMini Micro LiDAR Distance Sensor utilizes a Time-of-Flight (ToF) principle, measuring the round-trip time of a modulated 850nm infrared light pulse to calculate distance. This solid-state design, free of moving parts, provides stable and reliable ranging performance in both indoor and outdoor environments up to 70,000 Lux ambient light.
Its integrated optical and electronic design results in a compact, lightweight module with low power consumption, making it ideal for battery-powered mobile applications. The sensor outputs precise distance data via a simple UART serial protocol, compatible with a wide range of 5V logic microcontrollers and flight controllers.
Additional Information
| Weight | 0.007 kg |
|---|---|
| Dimensions | 4.2 × 1.5 × 1.6 cm |
