Benewake TF03 180M Long Distance Laser LiDAR Rangefinder Module - UART Interface, IP67
The Benewake TF03 is a single-point, long-range industrial LiDAR module utilizing 905nm pulse Time-of-Flight (ToF) technology for precise distance measurement from 0.1m to 180m. It features a UART interface for easy integration with drones, UAVs, robots, and automotive systems, operating from a 5-24V DC supply.
Features
- Extended 180m measurement range with ±10cm/1% accuracy
- High-speed 10kHz sampling rate and configurable 100-1000Hz frame rate
- Robust IP67-rated housing for reliable operation in harsh outdoor environments
- Wide 5-24V DC input voltage compatibility and UART communication interface
- Integrated compensation algorithm for excellent performance in high-light interference conditions
Out of stock
The TF03 is a third-generation industrial-grade laser rangefinder from Benewake, designed for demanding long-distance sensing applications. It employs a 905nm pulsed laser and advanced Time-of-Flight calculation to deliver stable, high-speed distance data. The module’s robust IP67 enclosure ensures protection against dust and water ingress, supporting reliable operation in outdoor and industrial settings from -20°C to +65°C.
Its configurable UART interface (default 115200 baud) and wide supply voltage range make it highly adaptable for integration into unmanned aerial vehicles (UAVs), autonomous mobile robots, intelligent transportation systems, and industrial safety monitoring platforms. The integrated highlight interference compensation allows for consistent performance even in challenging ambient light conditions.
Additional Information
| Weight | 0.08 kg |
|---|---|
| Dimensions | 4.29 × 4.4 × 3.18 cm |
