Arducam 8 MP Sony IMX219 Camera Module w/ M12 Lens LS40136 for Raspberry Pi
This Arducam module integrates an 8MP Sony IMX219 CMOS sensor with a standard M12 lens mount, designed for direct connection to Raspberry Pi 4, 3B+, and 3 via the dedicated CSI interface for high-resolution imaging and video capture.
Features
- 8MP Sony IMX219 Sensor: Delivers high-resolution 3280 x 2464 still images and supports 1080p30 video for clear, detailed visuals.
- Standard M12 Lens Mount (LS40136): Enables easy lens interchangeability for customizing field of view, focal length, and depth of field.
- Native Raspberry Pi CSI Interface: Plugs directly into Raspberry Pi 4, 3B+, and 3 models without requiring adapters or complex wiring.
- Integrated 650nm IR Filter: Provides balanced color reproduction for daylight conditions while maintaining IR sensitivity for potential night vision applications.
- Compact Form Factor: Measures just 36mm wide and weighs 15g, making it ideal for space-constrained embedded vision projects and portable devices.
Out of stock
The Arducam 8 MP camera module brings the popular Sony IMX219 image sensor to the Raspberry Pi ecosystem with enhanced flexibility. It connects via the standard Camera Serial Interface (CSI), providing a direct, high-bandwidth link for streaming high-resolution image data to the Pi’s GPU for processing. The inclusion of an M12 lens mount is a key differentiator, allowing developers and makers to swap lenses to achieve specific optical characteristics not possible with fixed-lens camera boards.
This module is engineered as a supplementary option to the official Raspberry Pi camera, addressing needs for different lens types, wider or narrower fields of view, and controlled depth of field. Its core IMX219 sensor is a proven 1/4-inch format CMOS component capable of capturing detailed 8-megapixel stills and smooth video up to 1080p at 30 fps or 720p at 60 fps. The built-in 650nm IR cut filter ensures accurate color rendition in typical lighting while the sensor’s inherent IR sensitivity opens doors for filtered night vision setups.
Additional Information
| Weight | 0.015 kg |
|---|---|
| Dimensions | 3.6 cm |
