AI-Thinker Ai-WB2-01S Wi-Fi & BLE 5.0 Module (BL602)
The AI-Thinker Ai-WB2-01S is a compact DIP-8 module featuring the BL602 chip, supporting dual-mode Wi-Fi 802.11b/g/n and Bluetooth 5.0 connectivity for low-power IoT applications. It is programmable via AT commands or SDKs like Bouffalo SDK and supports Arduino IDE for rapid prototyping.
Features
- Dual-mode Wi-Fi (802.11b/g/n) & Bluetooth 5.0 with Mesh support on a single BL602 RISC-V SoC.
- Ultra-low power operation with deep sleep current as low as 12μA for battery-powered sensor nodes.
- Integrated hardware security with AES-256, SHA, TRNG, and secure boot for robust IoT deployments.
- Compact DIP-8 package (14.5×24.5mm) with on-board PCB antenna for easy integration.
- Rich I/O including UART, PWM, ADC, and GPIO pins for sensor and peripheral interfacing.
Out of stock
The Ai-WB2-01S module from AI-Thinker is a highly integrated wireless communication solution built around the BL602 32-bit RISC-V processor. It combines a 2.4GHz Wi-Fi transceiver supporting up to 72.2 Mbps data rates with a full Bluetooth 5.0 stack, including Bluetooth Mesh, enabling versatile network topologies for smart home and industrial IoT systems.
Engineered for power-sensitive applications, the module features multiple sleep modes, with a deep sleep current of just 12μA, extending battery life in remote sensing deployments. Its hardware-accelerated cryptographic engine provides AES-256, SHA, and secure boot capabilities, ensuring data integrity and device authentication in connected environments.
Additional Information
| Weight | 0.015 kg |
|---|---|
| Dimensions | 5 × 5 × 2 cm |
