Adafruit Trinket M0 - ATSAMD21 Cortex M0+
The Adafruit Trinket M0 is a compact, low-cost microcontroller board built around the powerful Atmel ATSAMD21E18 Cortex M0+ processor. Maintaining the classic Trinket form factor, it offers greatly enhanced processing power, memory, and native USB, making it ideal for portable projects compatible with CircuitPython and the Arduino IDE.
Features
- Features ATSAMD21E18 Cortex M0+ processor for 32-bit performance.
- Offers 256KB Flash and 32KB RAM, a significant upgrade from ATtiny85.
- Native USB support for HID, serial, and CircuitPython disk drive functions.
- Pre-loaded with CircuitPython for easy Python programming; also Arduino IDE compatible.
- Maintains the ultra-compact Trinket form factor with enhanced capabilities.
Out of stock
The Adafruit Trinket M0 redefines compact embedded development, upgrading the beloved Trinket form factor with the formidable Atmel ATSAMD21E18 microcontroller. This tiny board packs a punch, featuring a 32-bit ARM Cortex M0+ processor clocked at 48 MHz, alongside 256KB of Flash memory and 32KB of RAM. This substantial performance boost over its 8-bit predecessors opens up new possibilities for complex, resource-intensive projects in an incredibly small footprint.
Designed for versatility and ease of use, the Trinket M0 offers native USB support, allowing it to function as a USB serial console, keyboard/mouse HID device, or even a small disk drive for CircuitPython scripts. It ships pre-loaded with CircuitPython, enabling rapid prototyping with Python – simply plug it in, edit `main.py` from the mounted drive, and your project is ready. For those who prefer C/C++, full compatibility with the Arduino IDE is also provided, offering flexibility for a wide range of embedded applications without needing to sacrifice an expensive development board.
Additional Information
| Weight | 0.003 kg |
|---|---|
| Dimensions | 10 × 3 × 2 cm |
