SKU: SENS-3829
📋 GST Invoice Available

ELA Innovation Blue PUCK T-PROBE Temperature Sensor (IDF25250-01B) - BLE Wireless Probe

₹8,449.00 (Inclusive of all taxes)
Out of Stock

The ELA Innovation Blue PUCK T-PROBE (IDF25250-01B) is a rugged, waterproof Bluetooth Low Energy (BLE) temperature probe designed for extreme industrial monitoring. With a wide sensing range from -80°C to +200°C and autonomous battery operation, it is ideal for cold chain logistics, pharmaceutical transport, and harsh environment temperature tracking.

Features

  • Wide-range BLE temperature probe for -80°C to +200°C monitoring.
  • Rugged, waterproof (IP68-equivalent) construction for harsh industrial environments.
  • Fully autonomous operation powered by an internal lithium battery for long-term deployment.
  • Bluetooth Low Energy (BLE) wireless communication for easy data logging and cold chain tracking.
  • Standard firmware included, with premium features available via firmware upgrade (V4.X.X).

Out of stock

Description

The ELA Innovation Blue PUCK T-PROBE is a specialized wireless temperature sensor engineered for reliability in demanding applications such as pharmaceutical cold chain logistics and industrial process monitoring. It utilizes Bluetooth Low Energy (BLE) technology to transmit temperature data, enabling remote monitoring without wired connections. The probe is built to withstand harsh conditions, featuring a robust, waterproof housing that protects its internal electronics.

Operating on an internal lithium battery, the sensor is designed for long-term autonomous use, making it suitable for tracking temperature-sensitive goods during transportation and storage. The device comes pre-loaded with standard firmware, while advanced configuration and features are accessible through a firmware upgrade and require a compatible NFC reader for setup. This combination of wide measurement range, environmental durability, and wireless connectivity provides a reliable solution for critical temperature assurance.

Key Features

  • Extended temperature measurement range from -80°C to +200°C for versatile cold and heat monitoring.
  • Bluetooth Low Energy (BLE 2.4 GHz) wireless interface for low-power, reliable data transmission.
  • Ruggedized, waterproof enclosure designed to perform in harsh industrial and outdoor environments.
  • Long-life internal lithium battery enables 100% standalone, cable-free operation.
  • Standard firmware (V.3.X.X) supports core logging; V4.X.X firmware unlocks advanced Bluetooth features.
  • Optimized for cold chain traceability and monitoring of pharmaceuticals, food, and chemicals.
  • Requires a compatible NFC reader for device configuration and parameter adjustment.

Applications

  • Pharmaceutical and vaccine cold chain logistics and temperature monitoring during transport.
  • Industrial process monitoring in harsh environments (e.g., manufacturing, chemical plants).
  • Food safety and quality assurance for perishable goods storage and distribution.
  • Environmental monitoring in remote or difficult-to-wire locations.
  • Laboratory and research applications requiring wireless temperature data logging.

Technical Specifications

Manufacturer Part NumberIDF25250-01B
BrandELA Innovation
Sensor TypeTemperature Probe
Measurement Range-80°C to +200°C
Wireless TechnologyBluetooth Low Energy (BLE)
Operating Frequency2.4 GHz
Power SupplyInternal Lithium Battery
Device Operating Temperature-40°C to +85°C
Enclosure RatingWaterproof (Rugged Industrial)
Firmware VersionStandard V.3.X.X (Premium V4.X.X available)
Configuration InterfaceNFC (Reader Required)
Shipping Weight0.035 kg
Shipping Dimensions13 × 10 × 3 cm

Frequently Asked Questions

What is the wireless communication range of the ELA Innovation T-PROBE sensor?

The sensor uses Bluetooth Low Energy (BLE), which typically offers a reliable range of up to 30 meters in open space, though actual range can be reduced by walls, metal obstructions, or other RF interference common in industrial settings. For configuration, an NFC reader must be brought into close proximity with the device.

How is the sensor powered and what is its battery life?

The sensor is powered by an internal, non-replaceable lithium battery designed for long-term autonomous operation. The exact battery life depends on the configured data logging interval and environmental conditions, but it is engineered for extended use in continuous monitoring applications, often lasting for months or years on a single charge.

Can this sensor be used for monitoring temperatures below freezing?

Yes, the ELA Innovation T-PROBE is specifically designed for an extended range from -80°C to +200°C, making it perfectly suitable for deep-freeze and cryogenic applications such as pharmaceutical cold chain, frozen food storage, and industrial cold process monitoring. The device's own operating temperature is rated from -40°C to +85°C.

What is required to configure the sensor and access advanced features?

Initial configuration and parameter setting require a compatible NFC reader. The device ships with standard firmware (V.3.X.X). To unlock premium Bluetooth advanced features like enhanced advertising modes or data formatting, a firmware upgrade to V4.X.X is necessary, which typically must be performed by the manufacturer or an authorized service provider.

Package Includes

  • 1 x ELA Innovation Blue PUCK T-PROBE Temperature Sensor (IDF25250-01B)

Additional Information

Weight 0.035 kg
Dimensions 13 × 10 × 3 cm
