AKM AK09911C Geomagnetic Hall Sensor Module - I2C Interface

The AK09911C sensor core operates from 1.7V to 3.6V for the I2C communication and digital logic supply (VDD). Ensure your microcontroller's I2C logic levels are compatible, typically 3.3V, for reliable communication without requiring a level shifter.

Connect the module's VCC (3.3V), GND, SDA, and SCL pins to the corresponding pins on your Arduino. Use an I2C library such as 'Wire.h' and the sensor's default address (0x0C) to initiate communication. The sensor supports single-measurement or continuous-mode data reads for magnetic field strength on all three axes.

In single measurement mode, the sensor takes one reading and then enters a power-saving state, ideal for battery-powered applications. Continuous mode periodically takes measurements at a set data output rate, providing a stream of real-time data for dynamic orientation tracking or navigation systems.

Yes, the AK09911C is designed for digital compass applications. By measuring the Earth's magnetic field Vector Technics across three axes, the sensor provides the raw data needed to calculate heading. Software algorithms are required to compensate for hard and soft iron distortions (calibration) for accurate heading output.

This module is supplied as a bare PCB with pre-soldered header pins. It does not include an enclosure or specific mounting hardware. For permanent installation, consider designing a custom mount or 3D-printed case to protect the board and secure it in your application.
