Skyzone Cobra Lite V2 FPV Goggles

₹11,969.00 (Inclusive of all taxes)
Out of Stock

The Skyzone Cobra Lite V2 is a lightweight, entry-level FPV goggle featuring a 480×272 LCD screen, 5.8GHz 48-channel diversity receiver, and integrated DVR, powered by a single 18650 battery or USB-C 5V input.

Features

  • 5.8GHz 48-channel diversity receiver for stable video reception.
  • Integrated DVR records in H.264/MJPEG format at 30 FPS up to 32GB.
  • Dual power options: single 18650 battery or USB-C 5V input.
  • Compact and lightweight design with a 50° FOV 16:9 LCD screen.
  • Intuitive shuttle wheel control for easy menu navigation.

Out of stock

Description

The Skyzone Cobra Lite V2 FPV Goggles offer a streamlined, cost-effective entry into the world of FPV flying. Designed as the ‘Lite’ variant of the Cobra series, it prioritizes simplicity and portability with a compact form factor powered by a single 18650 cell or a standard USB-C cable, making it ideal for field use without heavy battery packs.

Its core video system centers on a 5.8GHz 48-channel diversity receiver, which automatically selects the strongest signal from two antennas to minimize dropouts. The integrated digital video recorder (DVR) captures flight footage in H.264/MJPEG format at 30 frames per second, storing it on a microSD card up to 32GB capacity for post-flight analysis or sharing.

Key Features

  • 5.8GHz 48-channel diversity receiver with dual-antenna inputs for robust signal acquisition.
  • Integrated H.264/MJPEG DVR records at 30 FPS with support for microSD cards up to 32GB.
  • Flexible power system accepts a single 18650 Li-ion battery or 5V USB-C input for extended runtime.
  • Compact, lightweight chassis designed for comfort and portability during long flying sessions.
  • User-friendly interface with a shuttle wheel for intuitive control of channel scanning, DVR, and OSD settings.
  • 16:9 aspect ratio LCD display with a 50-degree field of view provides a clear, wide viewing experience.

Applications

  • Entry-level and beginner FPV quadcopter and airplane pilots.
  • Lightweight setup for micro and whoop-class drone racing and freestyle.
  • Portable field monitor for drone pilots who prioritize minimal gear weight.
  • Backup or spectator goggles for shared flying experiences.

Technical Specifications

Model NameCobra Lite V2
Screen TypeLCD
Screen Resolution480 x 272
Receiver TypeDiversity
Receiver Frequency5.8GHz (48 Channels)
DVR FormatH.264 / MJPEG, 30 FPS
Max DVR Storage32GB microSD Card
Field of View (FOV)50°
Aspect Ratio16:9
Power Input1x 18650 Battery or USB-C 5V
Power Consumption5V, ~1.4A
Product Length165 mm
Product Width122 mm

Frequently Asked Questions

What power sources are compatible with the Skyzone Cobra Lite V2 goggles?

The Cobra Lite V2 is designed for flexibility, accepting power from a single 18650 Li-ion battery (not included) or via a standard USB-C cable providing 5V input. This dual-power capability allows for easy field charging or extended runtime with spare 18650 cells.

What video formats and frame rates does the built-in DVR support?

The integrated digital video recorder captures footage in H.264 or MJPEG format at 30 frames per second. It records onto a microSD card (not included) with a maximum supported capacity of 32GB, suitable for reviewing flights or sharing clips.

Is the receiver module in these goggles upgradeable or replaceable?

No, the 5.8GHz 48-channel diversity receiver is integrated into the main board of the Cobra Lite V2 and is not designed to be user-upgradable or swapped out. This design contributes to the compact and cost-effective nature of this entry-level goggle model.

Package Includes

  • 1 x Skyzone Cobra Lite V2 FPV Goggles

Additional Information

Weight 0.65 kg
Dimensions 16.5 × 12.2 cm
