10cm IPEX 1 to RP-SMA Female Cable RG178
This 10cm RG178 cable provides a low-loss, flexible interface between IPEX (u.FL) connectors on compact wireless modules and RP-SMA female ports on external antennas or enclosures, ideal for Wi-Fi, Bluetooth, and cellular IoT applications.
Features
- Interface Conversion: Bridges IPEX 1 (u.FL) connectors on modules to RP-SMA female ports for external antenna connections.
- Low-Loss RG178 Coax: 11mm diameter RG178 coaxial cable ensures minimal signal attenuation for reliable RF transmission.
- Compact & Flexible: 10cm length and slim profile allow for easy routing in tight spaces within routers, drones, or IoT devices.
- Robust Connection: Secure locking RP-SMA and snap-on IPEX connectors provide a stable, vibration-resistant RF link.
- Universal Compatibility: Essential for connecting embedded Wi-Fi/Bluetooth/GPS modules (ESP32, nRF52840, SIMCom) to larger gain antennas.
Out of stock
This 10cm RF pigtail cable is engineered for reliable signal integrity in compact wireless designs. It utilizes a high-frequency RG178 coaxial core with precise 50-ohm impedance, minimizing VSWR and insertion loss to preserve RF power and sensitivity for Wi-Fi, Bluetooth, 4G, and GPS signals. The cable assembly features a secure IPEX 1 (u.FL) male connector on one end, designed for direct mating with ultra-small surface-mount antenna ports commonly found on ESP32, nRF52, and cellular modules.
The opposite end terminates in a reverse-polarity SMA (RP-SMA) female jack, the standard interface for many external Wi-Fi and cellular antennas. The 10cm length offers sufficient flexibility for internal device layout while keeping cable runs short to prevent excessive signal degradation. Its robust construction ensures reliable performance in consumer electronics, IoT gateways, and portable communication equipment.
Additional Information
| Weight | 0.005 kg |
|---|---|
| Dimensions | 9 × 7 × 1 cm |
