Waveshare TVOC Gas Sensor Module - UART Interface, 0.1-100ppm Range, 5V DC
Waveshare TVOC Gas Sensor Module - UART Interface, 0.1-100ppm Range, 5V DC - Image 2
Waveshare TVOC Gas Sensor Module - UART Interface, 0.1-100ppm Range, 5V DC - Image 3
SKU: SENS-0797
📋 GST Invoice Available

Waveshare TVOC Gas Sensor Module - UART Interface, 0.1-100ppm Range, 5V DC

₹999.00 (Inclusive of all taxes)
Out of Stock

The Waveshare TVOC Gas Sensor Module is a compact UART-based sensor designed for precise measurement of Total Volatile Organic Compounds (TVOC), COâ‚‚, and formaldehyde concentrations. It is compatible with 5V logic systems and includes development resources for integration with Raspberry Pi, Arduino, and ESP32 platforms.

Features

  • Measures TVOC, COâ‚‚, and CHâ‚‚O (formaldehyde) concentrations from 0.1ppm to 100ppm.
  • UART communication interface with a configurable 115200 bps baud rate.
  • Low power consumption with an operating current ≤60mA at 5V DC supply.
  • Compact form factor measuring just 27mm x 20mm for space-constrained applications.
  • Includes SH1.0 6-pin interface cable for immediate prototyping and connection.

Out of stock

Description

The Waveshare TVOC Gas Sensor employs a high-sensitivity sensing element to provide accurate environmental air quality assessment. Its design focuses on stable signal output and reliable performance for continuous monitoring applications within an operating temperature range of -20°C to 50°C.

The module outputs concentration data via a simple UART serial protocol, enabling straightforward integration into microcontroller-based systems and industrial data loggers. Its long-life sensor and low-power architecture make it suitable for deployed, battery-powered air quality monitoring stations and smart building automation systems.

Key Features

  • Multi-gas detection capability for comprehensive indoor air quality analysis.
  • Fast response time of less than 20 seconds for dynamic environmental monitoring.
  • Robust UART interface ensures reliable data transmission for system integration.
  • Compact and durable PCB construction optimized for embedded installations.
  • Includes comprehensive online development resources, manuals, and code examples.
  • Wide operating temperature range supports deployment in varied climatic conditions.

Applications

  • Indoor air quality monitoring and control systems for smart homes and offices.
  • Embedded environmental sensing in HVAC and building automation units.
  • Portable air quality detectors and personal environmental health monitors.
  • Integration into Raspberry Pi or ESP32-based data loggers for research and IoT networks.
  • Industrial safety and workplace exposure monitoring for volatile organic compounds.

Technical Specifications

Item TypeGas Sensor Module
Sensor TypeTVOC, COâ‚‚, CHâ‚‚O (Formaldehyde)
Operating Voltage5V DC
Operating Current≤60 mA
Operating Temperature-20°C to 50°C
Communication InterfaceUART
Baud Rate115200 bps (Configurable)
Detection Range0.1 ppm to 100 ppm
Response Time< 20 seconds
Dimensions (L x W)27 mm x 20 mm
Weight4 g

Frequently Asked Questions

What is the operating voltage range for this sensor?

The sensor requires a stable 5V DC power supply. Operating outside this specified voltage may damage the sensing element or produce inaccurate readings. Ensure your microcontroller or power source can provide a clean 5V rail.

How do I communicate with the sensor and what is the default protocol?

Communication is via a UART (serial) interface. The default baud rate is 115200 bps, but it is often configurable by sending specific command frames. Connect the module's TX and RX pins to your microcontroller's corresponding UART pins, ensuring logic level compatibility (5V).

What gases does this sensor detect and what is its measurement range?

This module detects Total Volatile Organic Compounds (TVOC), Carbon Dioxide (COâ‚‚), and Formaldehyde (CHâ‚‚O). The effective detection range for these gases is from 0.1 parts per million (ppm) up to 100 ppm, making it suitable for indoor air quality assessment.

Is this sensor suitable for outdoor or industrial environments?

Its operating temperature range of -20°C to 50°C allows for use in many controlled outdoor and indoor settings. However, for harsh industrial environments with extreme temperatures, high humidity, or corrosive gases, a sensor with a corresponding IP rating and more robust housing would be recommended.

Package Includes

  • 1 x Waveshare TVOC Gas Sensor Module
  • 1 x SH1.0 6-pin Interface Cable

Additional Information

Weight 0.004 kg
Dimensions 2.7 × 2 cm
