TS5823 200mW 40CH Mini Video Transmitter Module - RP-SMA/SMA
The TS5823 is a compact 5.8GHz 200mW video transmitter module supporting 40 channels, designed for micro and small FPV drones requiring a lightweight, low-current video link.
Features
- 5.8GHz 40CH video transmitter with 200mW RF output power.
- Wide 7-24V input voltage range for compatibility with 2S to 6S LiPo systems.
- Ultra-compact footprint measuring 40x20x8mm and weighing only 10g.
- Supports both RP-SMA and SMA antenna connector types.
- Low operating current of 0.19A for minimal power system drain.
Out of stock
The TS5823 Mini Video Transmitter provides a reliable, low-power video transmission solution for micro FPV builds, CineWhoops, and small multirotors. Its 7-24V input range allows direct connection to a wide array of flight controller BECs or LiPo batteries without requiring a separate voltage regulator.
Engineered for clean signal transmission, it features an 8MHz video bandwidth and 6.5MHz audio bandwidth, ensuring crisp FPV feed quality. The module’s aluminum casing aids in heat dissipation during sustained operation, maintaining stable performance across an operating temperature range of -10°C to 85°C.
Additional Information
| Weight | 0.015 kg |
|---|---|
| Dimensions | 4 × 2 × 0.8 cm |
