TE Connectivity HTU31V Temperature and Humidity Sensor, 0 to 100% RH, -40°C to 125°C, Analog Output, DFN-6 Package
The TE Connectivity HTU31V is a high-precision analog temperature and humidity sensor in a compact DFN-6 package, offering a wide operating range of -40°C to 125°C and 0-100% RH. Its analog output provides straightforward integration into industrial control systems, data loggers, and environmental monitoring applications requiring reliable, real-time sensing.
Features
- High-precision analog output for temperature and humidity sensing
- Wide operating range: -40°C to 125°C and 0-100% RH
- Compact DFN-6 package with robust epoxy encapsulation
- Low power consumption, suitable for battery-powered systems
- 30 AWG silver-plated copper leads with PTFE insulation for stability
Out of stock
The HTU31V from TE Connectivity is a fully integrated analog sensor designed for demanding environmental monitoring. It combines a capacitive humidity sensing element with a band-gap temperature sensor, delivering calibrated analog voltage outputs proportional to relative humidity and temperature. The sensor’s thermally conductive epoxy encapsulation ensures stable performance and protects the MEMS die from environmental contaminants.
Engineered for reliability across a broad industrial temperature span, the HTU31V features fast response times and low hysteresis. Its simple analog interface eliminates the need for complex digital communication protocols, making it ideal for direct connection to microcontrollers with ADC inputs or legacy analog control systems. The PTFE-insulated leads provide excellent chemical resistance and mechanical durability for long-term installations.
Additional Information
| Weight | 0.00002 kg |
|---|---|
| Dimensions | 0.25 × 0.25 cm |
