TBS Unify Pro32 HV (MMVTXCX) Video Transmitter
The TBS Unify Pro32 HV (MMVTXCX) is a high-voltage, high-power video transmitter designed for competitive FPV racing and freestyle drones. It integrates PitMode, SmartAudio V2.1, and CRSF for remote control via Betaflight OSD, supporting interference-free channel management and team-race coordination.
Features
- High-voltage design supporting up to 1000mW+ output power for robust signal penetration.
- Integrated PitMode reduces power to sub-1mW for zero-interference bench testing during races.
- Full UART control via SmartAudio V2.1 and CRSF for remote adjustment of power, band, and channel.
- CleanSwitch technology ensures interference-free power-up and channel switching.
- Double-decker PCB design with integrated heatsink for superior thermal management and durability.
Out of stock
The TBS Unify Pro32 HV is engineered for the demanding environment of organized FPV racing. Its high-voltage power supply ensures stable, high-output transmission even on 6S LiPo systems, while the advanced PitMode feature allows pilots to power and test their quads on the starting grid without disrupting other racers’ video feeds. This capability, combined with team-race functionality, makes it a cornerstone of modern race event logistics.
Control and configuration are fully integrated into the pilot’s workflow via SmartAudio V2.1 and CRSF telemetry. Adjustments for output power, frequency band, and channel can be made directly from the transmitter or through the Betaflight OSD, eliminating the need for physical buttons during flight. The robust RF amplifier is designed to withstand accidental operation without an antenna, protecting the unit from damage during pre-flight checks.
Additional Information
| Weight | 0.012 kg |
|---|---|
| Dimensions | 15 × 10 × 3 cm |
