Sensirion SHT31A-DIS-B2.5KS Humidity & Temperature Sensor - I2C Interface, AEC-Q100 Qualified
The Sensirion SHT31A-DIS-B2.5KS is an automotive-grade digital humidity and temperature sensor module with an I2C interface, designed for high-reliability applications. It provides fully calibrated, temperature-compensated measurements and is compatible with 3.3V and 5V microcontroller systems like Arduino, Raspberry Pi, and industrial PLCs.
Features
- Automotive-grade AEC-Q100 qualified for demanding environments
- High accuracy: ±2% RH and ±0.3°C typical
- Wide supply voltage range: 2.4 V to 5.5 V DC
- Fast I2C interface with speeds up to 1 MHz
- Extended operating range: -40°C to 125°C, 0% to 100% RH
Out of stock
The SHT31A-DIS-B2.5KS is a digital humidity and temperature sensor based on Sensirion’s CMOSens® technology, which integrates the sensor element, signal processing, and digital calibration on a single chip. This MEMS-based capacitive sensing principle ensures high signal integrity and long-term stability. The sensor’s output is fully linearized and temperature-compensated, providing reliable data for critical control systems.
Engineered for harsh conditions, this automotive-grade sensor meets AEC-Q100 qualification, ensuring performance across a wide temperature range with minimal drift. Its fast response time and low power consumption make it suitable for battery-powered or energy-sensitive applications requiring precise environmental monitoring.
Additional Information
| Weight | 0.0005 kg |
|---|---|
| Dimensions | 0.25 × 0.25 cm |
