Reflex Drive RD MI X8 8015 Motor 12S - CCW

The RD MI X8 8015 motor is rated for a 6S to 12S LiPo battery range. For optimal performance and to achieve the advertised 4KW peak power, a 12S battery pack is recommended. Always ensure your Electronic Speed Controller (ESC) is rated for the same voltage and current (90A peak) to match the motor's capabilities.

This motor is designed for large-diameter, high-pitch propellers typical of heavy-lift applications. The specifications list a maximum thrust of 16.64 kg when paired with 30x9 inch propellers. Always consult motor thrust tables and ensure your frame and ESC can handle the resulting torque and current draw from such large props.

This specific unit is a Counter-Clockwise (CCW) rotation motor. For a standard multirotor build (e.g., quadcopter, hexacopter), you will need to pair it with motors of the opposite rotation (CW) on the appropriate arms to provide the necessary torque for stable flight. The rotation direction is typically marked on the motor bell.

Due to its high torque 115KV rating, 4KW power output, and robust construction, this motor is ideally suited for demanding UAV applications. Primary uses include agricultural sprayer drones, heavy-lift cinematography platforms, industrial inspection rigs, and large-scale custom multirotor builds where maximum thrust and reliability are paramount.
