Quick Release Prop Adapter for 15-22" Props, M3 15mm Motor

Name: Quick Release Prop Adapter for 15-22" Props, M3 15mm Motor
Brand: Generic
SKU: DRFC-0300
Price: 839.00 INR
Availability: OutOfStock

₹839.00 (Inclusive of all taxes)

Out of Stock

This quick-release prop adapter set streamlines propeller installation and removal on multi-copters using 15-22 inch props. Designed for M3-15mm hole motors with 3mm, 3.17mm, or 4mm shafts, it enhances operational efficiency.

Features

Effortless propeller installation and removal for multi-copters.
Compatible with 15-22 inch propellers and M3-15mm hole motors.
Supports 3mm, 3.17mm, and 4mm motor shaft diameters.
Lightweight design, adding only 15g per pair to your drone.

Out of stock

Get Notified When Available

Description

The Quick Release Prop Adapter set is engineered to simplify propeller management on a wide range of multi-copter platforms. This innovative accessory eliminates the need for additional tools, allowing pilots to rapidly mount or dismount 15-22 inch propellers, significantly reducing pre-flight setup and post-flight teardown times.

Designed for motors with M3 screw holes and 15mm hole spacing, these adapters ensure a secure and balanced fit. They are compatible with various motor shaft diameters, including 3mm, 3.17mm, and 4mm, offering broad versatility across different drone builds. The inclusion of both CW and CCW adapters ensures correct rotational support for all motor configurations, enhancing both safety and operational efficiency.

Key Features

Facilitates rapid, tool-free propeller installation and removal.
Ensures secure and balanced mounting for 15-22 inch propellers.
Designed for motors with standard M3 screw holes and 15mm spacing.
Versatile compatibility with 3mm, 3.17mm, and 4mm motor shaft sizes.
Includes both Clockwise (CW) and Counter-Clockwise (CCW) adapters for full motor support.
Robust construction provides reliable performance during flight.

Applications

FPV freestyle drones (larger builds)
Cinematic multi-rotor platforms
Agricultural spraying drones
Long-range inspection UAVs
Heavy-lift multi-rotor aircraft

Technical Specifications

Type	Quick Release Propeller Adapter
Propeller Compatibility	15-22 inch
Motor Mount Compatibility	M3 screws, 15mm hole spacing
Motor Shaft Compatibility	3mm, 3.17mm, 4mm
Adapter Height (Red)	~11.3mm
Adapter Height (Grey)	~10.4mm
Weight	15g (per pair)
Screw Type	M3

Frequently Asked Questions

What propeller sizes are compatible with these adapters?

These quick-release prop adapters are specifically designed for 15-22 inch propellers. They ensure a secure and balanced fit for larger multi-copter applications, allowing for efficient power transfer from the motor to the propeller. This broad compatibility supports various heavy-lift or long-endurance drone builds effectively.

What motor types and shaft sizes do these adapters support?

The adapters are compatible with motors featuring M3 screw holes and a 15mm mounting circle. They also support multiple motor shaft diameters, specifically 3mm, 3.17mm, and 4mm. This versatility makes them suitable for a wide range of brushless motors commonly used in multi-rotor aircraft.

What is the primary benefit of using a quick-release prop adapter?

The main benefit is the ability to install and remove propellers rapidly without requiring any tools. This significantly reduces setup and breakdown times, enhancing operational efficiency for pilots and technicians. It's particularly advantageous for frequent transport, maintenance, or prop changes during field operations, ensuring convenience.

Are these adapters suitable for both CW and CCW motor rotations?

Yes, this set includes both Clockwise (CW) and Counter-Clockwise (CCW) quick-release prop adapters. This ensures full compatibility with all standard multi-copter motor configurations, preventing propeller loosening due to rotational forces and maintaining flight stability. Always ensure correct adapter orientation per motor.
