Pro-Range PR15C-PAS-050K Digital Pressure Sensor 0-50 kPa, 4-20mA Output, G1/4 Thread, 1m Cable
The Pro-Range PR15C-PAS-050K is a digital pressure transmitter delivering a 4-20mA analog output signal for precise 0-50 kPa gauge pressure monitoring. Designed for industrial PLCs, DAQ systems, and automation control panels, it features a G1/4 threaded process connection and a 1-meter cable for straightforward integration.
Features
- 0 to 50 kPa gauge pressure measurement range for low-pressure pneumatic and gas systems.
- Standard 4-20 mA two-wire analog output compatible with industrial PLCs and controllers.
- G1/4 threaded process connection for secure installation in pipelines and manifolds.
- Robust construction with ±0.5% FS accuracy and ≤5 ms response time.
- Includes a 1-meter shielded cable for direct electrical connection.
Out of stock
The PR15C-PAS-050K utilizes a high-stability sensing element to convert applied pressure into a proportional 4-20 mA current signal, providing reliable performance for industrial monitoring and control loops. Its compact, durable housing is engineered for use with air, gases, and non-corrosive fluids within an operating temperature range of -10°C to +70°C.
Featuring a standard G1/4 threaded port, this sensor ensures leak-proof installation in pneumatic systems, HVAC controls, and automation equipment. The integrated 1-meter cable simplifies wiring to power supplies and data acquisition modules, supporting a wide 12-24V DC input range for flexible system integration.
Additional Information
| Weight | 0.269 kg |
|---|---|
| Dimensions | 17.3 × 3 × 3 cm |
