Pro-Range PR15C-PAS-010 Digital Pressure Sensor 0-1MPa, 4-20mA Output, G1/4 Thread, 1m Cable
The Pro-Range PR15C-PAS-010 is a 4-20mA output pressure transmitter designed for industrial low-pressure monitoring up to 1 MPa. Featuring a G1/4 threaded port and a 1-meter integral cable, it provides a robust interface for PLCs, SCADA systems, and process control instrumentation.
Features
- 0 to 1 MPa (0 to ~145 psi) measurement range for low-pressure systems.
- Standard 4-20 mA analog current loop output for long-distance signal transmission.
- G1/4 industrial thread for secure installation in pneumatic or hydraulic lines.
- Wide 10-32 VDC supply voltage range compatible with common industrial power rails.
- Compact, durable housing with a 30mm diameter and 173mm length.
Out of stock
The PR15C-PAS-010 digital pressure sensor utilizes a high-stability sensing element to deliver accurate and reliable pressure readings for industrial automation, process control, and equipment monitoring. Its 4-20mA two-wire output provides inherent noise immunity and is the industry-standard signal for interfacing with PLC analog input modules, data loggers, and control panels.
Constructed with a corrosion-resistant body, this transducer is suitable for use with non-aggressive media such as air, water, and oils. The integrated 1-meter cable simplifies wiring, while the wide operating voltage ensures compatibility with various DC power supplies found in industrial environments.
Additional Information
| Weight | 0.273 kg |
|---|---|
| Dimensions | 17.3 cm |
