Pepperl+Fuchs NJ2-PD-US-2.062-V93 Inductive Proximity Sensor, 2mm Sensing Range, SPST-NO, 20-250V AC/DC, IP67
The Pepperl+Fuchs NJ2-PD-US-2.062-V93 is a rugged 2-wire inductive proximity sensor with a 2mm sensing range and SPST-NO (normally open) switching output. It operates on a wide 20–250V AC / 20–300V DC supply, making it directly compatible with industrial PLCs, machine controls, and high-voltage automation systems.
Features
- 2 mm rated sensing distance with 0–1.62 mm assured operating distance (sa).
- Wide-range 2-wire AC/DC operation (20–250V AC / 20–300V DC).
- SPST-NO (normally open) switching output for direct control integration.
- IP67-rated zinc housing for reliable operation in dusty, wet, or oily industrial environments.
- Integrated LED indicators for power, output status, and short-circuit diagnostics.
Out of stock
The NJ2-PD-US-2.062-V93 is an industrial-grade inductive proximity sensor designed for precise non-contact detection of metallic objects. It utilizes an electromagnetic field to sense the presence of ferrous and non-ferrous metals within its 2mm nominal range, providing a reliable SPST-NO switching signal. The sensor’s weld-immune design and 3000 psi dynamic pressure rating make it suitable for integration into hydraulic cylinder monitoring and heavy machinery.
Engineered for harsh environments, its zinc housing and IP67 protection ensure durability against dust ingress and temporary water immersion. The device features built-in safeguards including reverse polarity and short-circuit protection, enhancing system reliability. With a switching frequency up to 20 Hz and low voltage drop, it delivers stable performance for position feedback, limit switching, and automated counting tasks in industrial control panels and automation systems.
Additional Information
| Weight | 0.25 kg |
|---|---|
| Dimensions | 8.99 × 6.35 cm |
