Lite-On LTR-303ALS-01 DFN-6 Ambient Light Sensor ROHS
The Lite-On LTR-303ALS-01 is a digital ambient light sensor in a compact DFN-6 package, designed for automatic display brightness control and power management in portable electronics, IoT devices, and industrial panels. It features I2C digital output for easy integration with microcontrollers like Arduino, ESP32, and Raspberry Pi.
Features
- High-sensitivity digital ambient light sensor with I2C interface
- Wide dynamic range with automatic gain control for optimal performance
- Human-eye spectral response with integrated IR rejection filter
- Ultra-low power consumption for battery-powered applications
- Compact DFN-6 (2x2mm) package for space-constrained designs
Out of stock
The LTR-303ALS-01 from Lite-On is a sophisticated digital ambient light sensing (ALS) solution. It employs a photodiode array with a spectral response closely matched to the human eye, enhanced by an integrated infrared blocking filter to ensure accurate lux measurement under various lighting conditions, including artificial light. The sensor incorporates automatic gain selection to achieve a wide dynamic measurement range without external components.
Communication is handled via a standard I2C digital interface, providing direct lux readings and simplifying integration into embedded systems. Its robust design supports an operating temperature range from -30°C to 75°C, making it suitable for demanding environments. This sensor is ideal for implementing adaptive brightness control to enhance user experience and extend battery life in consumer and industrial electronics.
Additional Information
| Weight | 0.01 kg |
|---|
