HoneyComm HCBB07C IoT Beacon BLE 4.2 Asset Tracker

Name: HoneyComm HCBB07C IoT Beacon BLE 4.2 Asset Tracker
Brand: HoneyComm
SKU: IOWC-0099
Price: 649.00 INR
Availability: OutOfStock

₹649.00 (Inclusive of all taxes)

Out of Stock

The HoneyComm HCBB07C is a BLE 4.2 iBeacon tag designed for robust asset tracking and proximity sensing, featuring a tamper-proof alarm button and a 3-axis accelerometer for motion detection.

Features

BLE 4.2 iBeacon with configurable UUID, Major, and Minor values via mobile app for flexible deployment.
Integrated tamper-proof alarm button and 3-axis accelerometer sensor for asset removal alerts and motion state monitoring.
Extended 5-year battery life using dual ER14250 cells, optimized for ultra-low power operation in tracking applications.
Robust IP65 waterproof rating and wide operating temperature range (-40°C to 85°C) for demanding industrial environments.
Supports multiple installation methods including 3M adhesive backing or screw mounting for secure asset attachment.

Out of stock

Get Notified When Available

Description

The HoneyComm HCBB07C is a professional-grade Bluetooth Low Energy (BLE) beacon engineered for reliable IoT asset tracking and proximity marketing. Built around the BLE 4.2 protocol stack, it provides a stable and energy-efficient broadcast signal that can be detected by smartphones or gateways up to 80 meters away. Its core functionality extends beyond simple broadcasting with integrated anti-tamper protection and motion sensing.

This beacon incorporates a flexible alarm button that triggers an immediate broadcast alert if the device is removed from its mounted position, enhancing asset security. The onboard 3-axis accelerometer adds a layer of intelligence by detecting whether tagged assets or personnel are in motion, enabling more nuanced tracking scenarios. Designed for long-term deployments, its power management ensures multi-year operation from standard, user-replaceable lithium batteries, making it a set-and-forget solution for logistics, warehousing, and smart building applications.

Key Features

Standard iBeacon/Eddystone compatible BLE 4.2 tag for proximity sensing and asset identification.
Tamper-proof design with a flexible alarm button that broadcasts a removal signal instantly upon detachment.
Integrated 3-axis accelerometer sensor for detecting asset motion, tilt, or vibration events.
Ultra-low power consumption architecture enables up to 5 years of battery life with configurable broadcast intervals.
Fully configurable parameters (UUID, Major, Minor, TX Power, Adv. Interval) via dedicated mobile application.
Rugged IP65 waterproof enclosure suitable for both indoor and harsh outdoor industrial environments.
Dual mounting options with strong 3M adhesive backing and provision for screw fixation.
Wide operating temperature range from -40°C to 85°C for global deployment reliability.

Applications

Asset Tracking & Inventory Management in warehouses, factories, and logistics hubs.
Proximity Marketing & Indoor Navigation in retail stores, museums, and event venues.
Personnel & Equipment Safety Monitoring in industrial and healthcare settings.
Anti-Theft & Tamper Detection for high-value goods, tools, and medical devices.
Smart Building Automation for presence detection, room occupancy, and environmental control.

Technical Specifications

Wireless Protocol	Bluetooth Low Energy (BLE) 4.2, iBeacon
Frequency Range	2400MHz – 2483.5MHz
Broadcast Range	Up to 80 meters (0dBm TX Power)
Supply Voltage	3.0 VDC (Dual ER14250 or CR2032 batteries)
Average Current Consumption	7.0 µA (Typical, configurable)
Sensors	3-Axis Accelerometer, Tamper Button
Operating Temperature	-40°C to 85°C
Ingress Protection	IP65 (Water and Dust Resistant)
Dimensions (L x W)	44.5 mm x 25 mm
Weight	8.0 grams

Frequently Asked Questions

How do I configure the UUID, Major, and Minor values on the HCBB07C beacon?

You configure the HCBB07C beacon parameters using the dedicated HoneyComm mobile application for iOS or Android. After powering on the beacon, enable Bluetooth on your phone, open the app, and scan for nearby devices. Select the HCBB07C from the list to connect. Within the configuration menu, you can set the iBeacon UUID, Major, Minor values, broadcast power (TX), advertising interval, and the device name. Changes are written to the beacon's memory via BLE GATT commands immediately.

What triggers the tamper alarm, and how is the alert broadcast?

The tamper alarm is triggered when the flexible physical button on the beacon's casing is released, indicating the device has been detached from its mounted surface. Upon removal, the beacon immediately switches to a pre-defined alarm advertising mode, broadcasting a specific packet pattern. This alert can be detected by any BLE scanner or gateway listening for that pattern. The alarm state typically uses a faster broadcast interval to ensure rapid detection until the beacon is reset or re-attached.

What is the expected battery life, and how does broadcast interval affect it?

Using two ER14250 lithium batteries, the HCBB07C can achieve up to 5 years of life under optimal conditions: a broadcast interval of 10 seconds and a transmit power of 0dBm. Increasing the broadcast frequency (e.g., to 1 second) or raising the TX power will increase current draw, proportionally reducing battery lifespan. The ultra-low 7µA average current in deep sleep between broadcasts is key to the extended longevity. Always use high-quality, fresh batteries for best results.
