HaiWang HW-68 1/6W 10k 3000PPM PTC-Linear Thermistor
The HaiWang HW-68 is a 1/6W, 10kΩ PTC linear thermistor designed for precise temperature sensing and control applications. It offers a linear resistance increase with temperature (3000 PPM) across a wide operating range of -40°C to 180°C, making it compatible with various analog and digital circuit designs for temperature monitoring.
Features
- PTC Linear Thermistor with 10kΩ nominal resistance at 25°C
- Wide operating temperature range from -40°C to +180°C
- Linear resistance-temperature characteristic (3000 PPM) simplifies circuit design
- Compact, durable SMD package suitable for automated PCB assembly
- 1/6W power rating for reliable operation in various sensing applications
Out of stock
The HW-68 PTC linear thermistor utilizes a positive temperature coefficient (PTC) material, where its electrical resistance increases linearly with rising temperature. This predictable 3000 PPM coefficient enables straightforward integration into temperature sensing circuits without complex linear compensation, providing a stable analog voltage signal proportional to temperature changes.
Constructed with a durable SMD package that meets standard resistor footprints, it is designed for reliable performance in harsh environments. Its operational range from -40°C to 180°C makes it suitable for applications requiring monitoring beyond typical electronic device limits, offering a high-value alternative to platinum RTDs like PT100/PT1000 in many scenarios below 180°C.
Additional Information
| Weight | 0.01 kg |
|---|---|
| Dimensions | 1.2 × 0.8 × 0.2 cm |
