Name: Generic Automatic Sanitizer Dispenser Control Board | Integrated IR Sensor | Relay Output Control
Brand: Generic
SKU: OL-GEN-SDCBIR
Price: 149.00 INR
Availability: InStock

Touchless Activation

Ensures superior hygiene by eliminating physical contact, promoting a safer environment effortlessly.

Integrated Control Logic

Simplifies system design by combining sensing and actuation in one compact, efficient module.

Robust Pump Interface

Drives high-current pumps directly, offering powerful, reliable control for consistent liquid dispensing.

The Engineering Behind Automatic Sanitizer Dispenser Control Board

This dedicated control board forms the intelligent core of automated sanitizer dispensing systems, expertly integrating an infrared (IR) proximity sensor for touchless activation and a robust relay for precise pump control. Its architecture is optimized for real-time response, detecting hand presence and initiating the dispensing cycle with minimal latency. The design prioritizes operational reliability and ease of integration into various enclosure designs.

Constructed with industrial-grade components and a durable PCB, this module ensures long-term stability and resistance to typical environmental factors in high-traffic areas. Its robust build quality makes it suitable for both DIY projects and semi-industrial deployment, offering consistent performance without compromise.

Integrated Infrared Proximity Sensing

The primary technical feature is its highly responsive infrared proximity sensor, providing accurate, non-contact hand detection. This integration eliminates the need for external sensing modules, simplifying system design and reducing component count. The sensor’s rapid detection capabilities ensure instantaneous activation of the dispensing mechanism upon hand presentation, enhancing user experience and hygiene.

High-Current Relay Output

A crucial secondary feature is the onboard high-current relay, designed to directly control various types of dispenser pumps, including peristaltic, diaphragm, or solenoid valves. This robust switching capability resolves common operational pain points by safely isolating the low-voltage control circuitry from the higher power requirements of pump motors, ensuring reliable and long-lasting performance for the actuator without requiring an external driver board.

Optimized for Performance & Integration

Input Voltage: 5V – 12V DC (typical)
Sensor Type: Infrared Proximity Sensor
Relay Output: SPDT (Single Pole Double Throw), rated up to 10A @ 250VAC / 10A @ 30VDC
Detection Range: Adjustable, typically 2cm – 10cm
Control Logic: Active-low or active-high configurable via jumper
Interface: Screw terminal blocks for power and load
Mounting: Standard PCB mounting holes

Features & Benefits

Integrated IR Sensor: Enables automatic, touchless operation for enhanced hygiene and user convenience.
Robust Relay Output: Directly controls various pump types, simplifying wiring and reducing external component needs.
Wide Voltage Compatibility: Operates reliably across 5V to 12V DC, suitable for diverse power sources.
Adjustable Detection Range: Customizable sensitivity for different dispenser designs and environmental conditions.
Compact & Integrated Design: Streamlines installation, reduces footprint, and ensures a clean build.
Stable & Durable Construction: Built with quality components for long-term, dependable performance.

Pro-Grade Advantages

Seamless integration of sensing and actuation for rapid deployment.
High-current relay eliminates need for external power drivers for most pumps.
Compact form factor optimizes space utilization within dispenser enclosures.
Reliable touchless operation significantly improves hygiene standards.

Technical Considerations

Requires external power supply and pump (not included).
No advanced communication protocols (e.g., I2C, SPI) for system feedback.

What power supply voltage is recommended for this control board?

The control board typically operates within a 5V to 12V DC range, making it compatible with common power adapters and battery configurations. Always check the specific board’s silk screen for exact voltage input.

Can this board control different types of pumps?

Yes, the onboard relay is designed to switch various types of DC or AC pumps, including peristaltic, diaphragm, and solenoid valves, provided their current and voltage ratings do not exceed the relay’s specifications (e.g., 10A @ 30VDC / 250VAC).

Is the infrared sensor’s detection range adjustable?

Many versions of this board offer a potentiometer to fine-tune the IR sensor’s detection range, allowing customization from typically 2cm to 10cm to suit different dispenser designs and activation distances.

Does this control board provide feedback or a control signal for external microcontrollers?

This particular board is designed as a standalone control unit, primarily focusing on direct actuation. It generally does not offer advanced data feedback or dedicated communication lines for external microcontrollers beyond its operational state.

How should I connect the pump to the relay output?

Connect the pump’s power line through the normally open (NO) and common (COM) terminals of the relay. Ensure the pump’s power supply is appropriate for the pump itself and the relay’s maximum switching capabilities.

Specification	Value
Input Voltage (DC)	5V – 12V
Sensor Type	Infrared Proximity
Detection Range	2cm – 10cm (Adjustable)
Relay Type	SPDT
Relay Contact Rating	10A @ 250VAC / 10A @ 30VDC
Control Logic	Configurable (Active-Low/High)
Output Interface	Screw Terminals
Mounting Holes	Standard PCB
Operating Temperature	-20°C to +70°C (typical)

Additional information

Brand	Generic
Technology	IR Proximity Sensing, Relay Control
Operating Voltage	5V – 12V DC
Control Interface	Electrical Screw Terminals
Sensor Type	Infrared Proximity
Output Signal	Relay (SPDT)
Load Capacity	10A @ 250VAC / 10A @ 30VDC
