Name: Generic 7404 NOT Logic Gate IC | Hex Inverting Gate | Standard TTL Logic
Brand: Generic
SKU: OL-GEN-7404NOT
Price: 45.00 INR
Availability: InStock

Versatile Inversion

Enables fundamental logic inversion for robust signal processing, essential for diverse digital circuit implementations efficiently.

Compact Design

Integrates six gates into a single chip, optimizing board space and simplifying complex circuit layouts significantly.

TTL Compatibility

Ensures seamless integration with existing 5V digital systems, guaranteeing reliable and proven operational performance.

The Engineering Behind 7404 NOT Logic Gate IC

The 7404 is a foundational Hex Inverting Gate Integrated Circuit, offering six independent NOT gates within a single package. Each gate performs logical inversion, where a high input yields a low output, and a low input yields a high output. This component is crucial for implementing basic digital logic functions, creating clock signals, or building more complex combinatorial circuits by integrating with other logic families.

Manufactured in a robust 14-pin Dual In-line Package (DIP), the 7404 adheres to industry-standard TTL (Transistor-Transistor Logic) specifications, ensuring broad compatibility and dependable operation in diverse electronic systems. Its solid-state construction guarantees long-term durability and consistent signal integrity, essential for both educational applications and professional prototyping.

Six Independent Inverters

The primary strength of the 7404 lies in its six fully independent NOT gates, enabling designers to perform multiple inversion operations concurrently without requiring additional chips. This compact architecture minimizes board space and simplifies circuit layout, providing efficient utilization of resources in complex digital designs and optimizing component count.

Standard TTL (Transistor-Transistor Logic) Compatibility

Adherence to the widely adopted TTL logic family ensures seamless integration with a vast ecosystem of existing digital components and systems operating at a nominal 5V. This eliminates compatibility concerns and reduces the need for complex level-shifting circuitry, accelerating development cycles and enhancing project robustness by relying on proven, industry-standard logic thresholds.

Optimized for Performance & Integration

Logic Family: TTL (Transistor-Transistor Logic)
Number of Gates: 6 (Hex Inverter)
Package Type: DIP-14 (Dual In-line Package, 14-pin)
Operating Voltage (VCC): 4.75V to 5.25V (Nominal 5V)
Propagation Delay: Typically 10 ns (for LS variant)
Output Drive: Standard TTL output current sourcing/sinking
Operating Temperature: 0°C to 70°C (Commercial)
Pin Configuration: Standard 14-pin assignment for VCC, GND, and six IN/OUT pairs

Features & Benefits

Hex Inverting Gates: Provides six distinct NOT gate functions within a single IC, reducing component count and board space.
Standard TTL Logic: Ensures broad compatibility with 5V digital systems and other TTL logic family devices.
Wide Operating Voltage Range: Operates reliably from 4.75V to 5.25V, accommodating minor power supply fluctuations.
Low Propagation Delay: Delivers rapid signal inversion, crucial for high-speed digital applications and timing-critical circuits.
DIP-14 Package: Facilitates easy prototyping on breadboards and simplifies soldering for through-hole PCB designs.
Robust Construction: Guarantees long-term stability and consistent electrical characteristics under various operating conditions.

Pro-Grade Advantages

Industry-standard TTL logic for reliable and predictable operation.
Provides six independent NOT gates, optimizing component count.
Robust DIP-14 package for ease of prototyping and integration.
Essential building block for all digital logic circuit designs.

Technical Considerations

Limited to 5V nominal operating voltage, not suitable for lower voltage systems.
Higher power consumption compared to modern CMOS counterparts in quiescent state.

What is the primary function of a 7404 NOT gate IC?

The 7404 IC contains six independent inverting gates, often called NOT gates. Each gate produces an output that is the logical inverse of its input signal, making it fundamental for digital logic operations.

What is the typical operating voltage for the 7404?

The 7404, being a standard TTL (Transistor-Transistor Logic) device, typically operates with a VCC supply voltage of 5V, within a specified range of 4.75V to 5.25V.

How many NOT gates are included in a single 7404 package?

A single 7404 integrated circuit package provides six fully independent NOT gates, allowing multiple inversion functions to be implemented with one component.

Is the 7404 compatible with modern CMOS logic families?

While the 7404 is a TTL device, it can interface with some CMOS logic families with appropriate voltage level-shifting or by selecting compatible CMOS versions like the 74HC04, which operates over a wider voltage range.

What are common applications for the 7404 Hex Inverter?

Common applications include signal inversion, creating oscillators when combined with passive components, constructing basic logic gates, and as a buffer to increase driving capability or isolate stages in digital circuits.

Specification	Value
Logic Family	TTL (Transistor-Transistor Logic)
Number of Gates	6 (Hex Inverter)
Supply Voltage Range (VCC)	4.75V to 5.25V
Input High Voltage (Min)	2V
Input Low Voltage (Max)	0.8V
Output High Voltage (Min)	2.7V
Output Low Voltage (Max)	0.5V
Propagation Delay (Typ)	10 ns
Operating Temperature	0°C to 70°C
Package Type	DIP-14
Pins	14

Additional information

Weight	0.001 kg
Dimensions	1.93 × 0.635 × 0.457 cm
Brand	Generic
Technology	TTL (Transistor-Transistor Logic)
Operating Voltage	5V (4.75V – 5.25V)
Package	DIP-14
Channels	6 (Hex Inverter)
