Generic 1.3 Inch I2C OLED Display Module | SSD1306 Driver | White Pixel Resolution
₹149.00₹250.00 (price_including_tax) (-40%)
Experience crisp, high-contrast visuals with this 1.3-inch OLED display. Seamlessly integrate this module into your embedded systems, robotics, or DIY projects using its efficient I2C protocol. Built for reliability and consistent performance in various applications.
Precision white OLED display offering sharp visuals and efficient I2C interface for embedded projects.
Minimizes footprint in embedded systems, ideal for portable and space-constrained applications.
Simplifies wiring and coding, enabling rapid prototyping and development cycles effectively.
Delivers high-contrast, sharp text and graphics for clear data presentation consistently.
The Engineering Behind 1.3 Inch I2C OLED Display Module
The 1.3-inch I2C OLED Display Module is a self-emissive organic light-emitting diode screen driven by the ubiquitous SSD1306 controller. Utilizing an Inter-Integrated Circuit (I2C) communication protocol, it offers a simplified four-pin interface (VCC, GND, SCL, SDA) for data transfer, significantly reducing wiring complexity in micro-controller-based applications. Each pixel generates its own light, eliminating the need for a backlight and resulting in superior contrast ratios and true black levels.
Constructed with high-quality organic material and encased on a compact PCB, this module is designed for robust performance in diverse embedded environments. Its self-emissive nature ensures wide viewing angles and rapid response times, critical for dynamic data visualization and user interfaces in development boards and portable devices. The module’s compact form factor and low power consumption make it an ideal choice for battery-powered projects and space-constrained designs.
High-Contrast White Pixel Array
The primary technical feature is its high-contrast white pixel array, offering a resolution of 128×64. This specific monochromatic output provides exceptional clarity and readability even in varying ambient light conditions. The individual pixel control afforded by the OLED technology ensures deep blacks and bright whites, making text, icons, and graphical elements stand out with remarkable sharpness, which is superior to traditional LCDs without backlights.
Efficient I2C Serial Communication
The module leverages the I2C (Two-Wire Interface) serial communication protocol, which streamlines integration by requiring only two data lines (SDA and SCL) in addition to power and ground. This structural choice resolves traditional operational pain points associated with parallel interfaces or SPI, such as excessive pin count requirements, complex routing, and increased board space. The I2C interface supports multiple devices on the same bus, allowing for an organized and scalable hardware architecture.
Optimized for Performance & Integration
- Display Type: OLED Monochromatic
- Display Size: 1.3 Inch (diagonal)
- Resolution: 128×64 Pixels
- Color: White
- Driver IC: SSD1306
- Interface: I2C (4-pin)
- Operating Voltage: 3.3V – 5V DC
- Pinout: VCC, GND, SCL, SDA
Features & Benefits
- 1.3-inch OLED Display: Provides a clear, compact visual interface for data output.
- 128×64 Pixel Resolution: Ensures sharp graphics and readable text for complex data displays.
- I2C Communication: Simplifies wiring with only four pins, conserving microcontroller I/O resources.
- SSD1306 Driver: Offers robust, widely supported control for easy programming and integration.
- Wide Operating Voltage (3.3V-5V): Compatible with both 3.3V and 5V logic microcontrollers without level shifting.
- Self-Emissive White Pixels: Delivers high contrast, true blacks, and wide viewing angles for superior readability.
Pro-Grade Advantages
- High contrast ratio and true black levels due to self-emissive technology.
- Low power consumption, extending battery life in portable applications.
- Wide viewing angles and fast response times for dynamic interfaces.
- Simplified 4-pin I2C interface for easy integration with microcontrollers.
Technical Considerations
- Limited pixel burn-in susceptibility over extended periods of static display.
- Monochromatic display is unsuitable for applications requiring full-color visuals.
What is the operating voltage range for this 1.3-inch OLED module?
This 1.3-inch OLED module typically operates within a voltage range of 3.3V to 5V DC, making it compatible with a wide array of microcontrollers without additional level shifters.
Which communication protocol does this OLED display utilize?
The module employs the I2C (Inter-Integrated Circuit) serial communication protocol, requiring only two data lines (SDA, SCL) for efficient data transfer and control.
What is the resolution and color output of this display?
This display features a resolution of 128×64 pixels and outputs a crisp, monochromatic white color, ideal for clear text and graphical elements.
Is this OLED display suitable for outdoor applications?
While OLEDs offer good contrast, direct sunlight can reduce visibility. It’s best suited for indoor or shaded outdoor environments unless specifically enclosed or shielded.
What microcontroller driver IC is integrated into this module?
The module integrates the widely used SSD1306 driver IC, providing robust control and extensive library support across various development platforms like Arduino and Raspberry Pi.
| Specification | Value |
|---|---|
| Display Technology | OLED (Organic Light-Emitting Diode) |
| Display Size | 1.3 inches (Diagonal) |
| Resolution | 128 x 64 Pixels |
| Pixel Color | White |
| Driver IC | SSD1306 |
| Communication Interface | I2C (IIC) |
| Pin Configuration | 4-Pin (VCC, GND, SCL, SDA) |
| Operating Voltage | 3.3V – 5V DC |
| Viewing Angle | >160 Degrees |
| Operating Temperature | -30°C to 70°C |
Additional information
| Brand | Generic |
|---|---|
| Technology | OLED |
| Operating Voltage | 3.3V – 5V DC |
| Control Interface | I2C |
| Value | 128×64 pixels |
| Difficulty Level | Beginner to Intermediate |
