FlySky FS-ST16 16 Channel 2.4GHz Drone Transmitter
FlySky FS-ST16 16 Channel 2.4GHz Drone Transmitter - Image 2
FlySky FS-ST16 16 Channel 2.4GHz Drone Transmitter - Image 3
FlySky FS-ST16 16 Channel 2.4GHz Drone Transmitter - Image 4
SKU: DRFC-3362
📋 GST Invoice Available

FlySky FS-ST16 16 Channel 2.4GHz Drone Transmitter

₹27,429.00 (Inclusive of all taxes)
Out of Stock

The FlySky FS-ST16 is a 16-channel 2.4GHz radio transmitter featuring high-resolution Hall sensor gimbals, a large 3.5-inch IPS display, and dual-antenna signal reliability. It supports FlySky OS and open-source EdgeTX firmware for versatile model control across drones, planes, cars, and boats.

Features

  • 16-channel control with 4096-resolution Hall sensor gimbals for precise input.
  • 3.5-inch full-color IPS display (320×480) with sunlight-readable clarity.
  • Dual-antenna system (internal + external foldable) for robust 2.4GHz signal stability.
  • Powered by STM32H7 chip, supporting FlySky OS and open-source EdgeTX firmware.
  • USB Type-C port for charging, firmware updates, and model data backup.

Out of stock

Description

The FlySky FS-ST16 transmitter is engineered for demanding RC pilots and builders, combining a powerful STM32H7 processor with a flexible firmware ecosystem. Its high-gloss ergonomic body houses customizable switches and knobs, providing a professional-grade interface for complex multirotor and fixed-wing setups.

Electrical design prioritizes stable power delivery, accepting 6-9V DC input or dual 18650 LiPo cells, while the integrated dual-antenna system ensures consistent RF link integrity. The transmitter’s architecture supports extensive telemetry feedback and up to 40 model memories, making it a central hub for pilots managing diverse fleets.

Key Features

  • High-precision 4096-resolution Hall effect gimbals offer smooth, drift-free control.
  • Large 3.5-inch IPS touchscreen provides clear telemetry and menu navigation in all lighting conditions.
  • Dual-band antenna design with a built-in antenna and a foldable external antenna enhances signal penetration and range.
  • Open-source EdgeTX firmware compatibility allows for deep customization of mixes, scripts, and Lua apps.
  • Robust power system supports 2S LiPo (18650) batteries or DC input for extended operational sessions.
  • Ergonomic grip design and customizable physical controls (switches, knobs) adapt to various pilot preferences.
  • USB Type-C interface consolidates charging, firmware flashing, and SD card model data management.

Applications

  • Primary transmitter for 5-inch and 7-inch long-range FPV drones requiring 16-channel control for complex payloads.
  • Ideal platform for fixed-wing RC planes and jets utilizing advanced flight modes and telemetry.
  • Central control unit for scale RC car and boat projects demanding multiple proportional channels.
  • Development and testing transmitter for drone builders programming custom mixes via EdgeTX.
  • Competitive FPV racing where high-resolution gimbal input and low-latency signal are critical.

Technical Specifications

Model NumberFS-ST16
Channels16
RF Power< 20 dBm
Input Voltage6-9V DC / 2S LiPo (18650 x2)
Antenna SystemDual (Internal + External Foldable)
Display3.5-inch IPS, 320 x 480 pixels
Gimbal TypeHall Sensor (4096 resolution)
FirmwareFlySky OS, EdgeTX
Charging PortUSB Type-C
Model Memory40
Operating Temperature10°C to +60°C
Operating Humidity20% to 95%
Dimensions (LxW)224.1 x 180 mm
Weight (Transmitter)675 g

Frequently Asked Questions

What firmware does the FlySky FS-ST16 support?

The FS-ST16 natively runs FlySky OS but is fully compatible with the open-source EdgeTX firmware. This allows pilots to flash EdgeTX for access to its extensive customization features, including advanced mixer scripting, Lua applications, and a more flexible user interface, all while retaining full functionality with FlySky's AFHDS 3 protocol.

What type of batteries does the FS-ST16 transmitter use?

The transmitter is designed to operate on a 2S LiPo battery pack, typically using two 18650 cells, providing a voltage range of 6-9V. It also includes a USB Type-C port for convenient charging of the internal battery pack, eliminating the need for external chargers in many cases.

Is the included FS SR8 receiver compatible with FPV drones?

Yes, the included FS SR8 is an 8-channel PWM receiver compatible with the AFHDS 3 protocol. It is suitable for many FPV drone and fixed-wing builds, providing stable control and telemetry feedback. For drones requiring serial protocols like SBUS or CRSF, you would need to use a separate FlySky serial receiver compatible with the FS-ST16.

Package Includes

  • 1 x FlySky FS-ST16 Transmitter
  • 1 x FS SR8 Receiver
  • 1 x Connecting Cable
  • 1 x Binding Cable
  • 1 x User Guide

Additional Information

Weight 0.675 kg
Dimensions 22.41 × 18 cm
