EByte E105-WBS36-TB NearLink WiFi 6 & BLE 5.4 Combo Module Test Kit

₹899.00 (Inclusive of all taxes)
Out of Stock

The EByte E105-WBS36-TB is a development board for the E105-WBS36S combo module, integrating WiFi 6, Bluetooth 5.4, and Flash memory. USB-powered with a UART interface, it facilitates rapid prototyping and firmware development for IoT and wireless applications.

Features

  • Integrated Combo Module: Features the E105-WBS36S module with WiFi 6, Bluetooth 5.4 (BLE), and integrated Flash memory for comprehensive wireless connectivity.
  • USB-Powered & UART Interface: Simplifies power supply and communication, enabling straightforward programming, debugging, and serial data exchange.
  • Breadboard-Compatible Design: Compact 60x34mm PCB with full GPIO pin breakout allows for easy integration with sensors and peripherals during prototyping.
  • Industrial Temperature Range: Operates reliably from -40°C to +85°C, making it suitable for demanding IoT and embedded system environments.

Out of stock

Description

The EByte E105-WBS36-TB Test Kit is an entry-level development platform centered on the E105-WBS36S 3-in-1 wireless module. This module combines WiFi 6 for high-throughput local networking, Bluetooth 5.4 for low-power device connectivity, and on-chip Flash memory for firmware and data storage. The board provides a streamlined path from concept to deployment by breaking out all module pins to standard headers and incorporating a USB-to-UART bridge for power and serial communication.

Designed for flexibility, the board’s breadboard-friendly footprint and industrial-grade operating temperature range support a wide spectrum of IoT development, from educational prototyping to industrial telemetry and smart home automation projects. The integrated antenna connector ensures optimal RF performance for both WiFi and BLE protocols.

Key Features

  • Triple Wireless Integration: Combines WiFi 6 (802.11ax), Bluetooth 5.4 Low Energy, and NearLink support in a single compact module.
  • Onboard Flash Memory: Integrated storage simplifies firmware updates and data logging without external components.
  • Developer-Friendly Interface: USB Micro-B port provides both power and a direct UART serial connection for AT command control and firmware flashing.
  • Full GPIO Access: All module pins are broken out to standard 2.54mm pitch headers, enabling direct connection to sensors, displays, and actuators.
  • Robust Construction: Supports an industrial operating temperature range from -40°C to +85°C for reliable performance in harsh environments.
  • Included RF Antenna: Comes with an external SMA antenna to ensure good wireless signal strength and range for development testing.

Applications

  • IoT Device Prototyping: Rapid development of smart home sensors, wearables, and wireless controllers.
  • Wireless Communication Testing: Evaluation and testing of WiFi 6 and BLE 5.4 coexistence and performance.
  • Educational & Maker Projects: Learning platform for embedded systems and wireless networking concepts.
  • Industrial IoT (IIoT) Telemetry: Building robust remote monitoring nodes for industrial environments.

Technical Specifications

Supported ModuleE105-WBS36S Combo Module
Wireless ProtocolsWiFi 6 (802.11ax), Bluetooth 5.4 (BLE), NearLink
Flash MemoryIntegrated
Power Supply5V via USB Micro-B
Communication InterfaceUART (USB-CDC)
GPIO AccessFull pin breakout on headers
Antenna ConnectorSMA (external antenna included)
Operating Temperature-40°C to +85°C
Operating Humidity10% – 90% RH (non-condensing)
Board Dimensions60 x 34 mm

Frequently Asked Questions

How do I power and communicate with the E105-WBS36-TB board?

Connect the provided Micro-USB cable from your computer or a 5V USB adapter to the board's Micro-B port. This supplies power and establishes a USB-CDC virtual COM port for UART communication. Use a serial terminal application (e.g., PuTTY, Arduino Serial Monitor) at the appropriate baud rate (default is often 115200) to send AT commands or receive debug output from the module.

What software or IDE is needed to program the onboard E105-WBS36S module?

Development typically involves using the manufacturer's SDK or AT command set. You may need to install USB-to-UART bridge drivers for your operating system to recognize the COM port. For advanced firmware development, consult EByte's documentation for the specific toolchain, which may involve a proprietary IDE or integration with common embedded development environments for compiling and flashing code to the module's integrated Flash memory.

How do I connect an external antenna, and is one included?

Yes, an external SMA antenna is included in the kit. Simply screw it onto the SMA female connector located on the development board. Ensure it is hand-tightened securely for proper impedance matching and optimal RF performance. This antenna is used for both the WiFi 6 and Bluetooth 5.4 radios, providing better range and signal stability compared to a hypothetical onboard ceramic antenna.

Package Includes

  • 1 x EByte E105-WBS36-TB NearLink Combo Module Test Kit (Development Board)
  • 1 x External SMA Antenna
  • 1 x USB-A to Micro-USB Cable

Additional Information

Weight 0.01 kg
Dimensions 5 × 5 × 2 cm
