TCRT5000 Reflective IR Sensor Photoelectric Switch Pack of 5
The TCRT5000 is a reflective infrared photoelectric switch module, ideal for line-following robots and proximity detection in Arduino, Raspberry Pi, and other 3.3V/5V microcontroller projects, with a typical sensing range of up to 15mm.
Features
- Reflective IR sensing principle for non-contact object detection.
- Compact, integrated IR emitter and phototransistor receiver.
- Wide operating voltage range of 3.6V to 5V DC.
- High collector-emitter voltage rating of 70V and current handling up to 100mA.
- Pack of 5 sensors for multi-channel or backup applications.
Out of stock
The TCRT5000 sensor integrates an infrared LED emitter and a silicon NPN phototransistor in a compact, side-looking package. It operates on the principle of reflective sensing, where the emitted IR beam reflects off a surface back to the phototransistor. The intensity of the received signal varies with the reflectivity and distance of the object, providing a simple digital or analog output for detection.
Designed for robustness, the sensor features a plastic housing with an iron base for mounting stability. It is compatible with common 3.3V and 5V logic systems, making it a standard component for educational robotics, automated guided vehicles (AGVs), and basic industrial counting or sorting applications where precise, long-range detection is not required.
Additional Information
| Weight | 0.012 kg |
|---|---|
| Dimensions | 3 × 4 × 1 cm |
