Pro-Range D8120-100DKV CW Brushless Drone Motor
The Pro-Range D8120-100DKV CW is a high-power brushless motor engineered for heavy-lift and industrial UAV platforms. Operating on 6S to 12S LiPo battery systems, it delivers up to 1400W of power with a focus on efficiency and thermal durability for extended flight endurance.
Features
- Low KV rating of 100 rpm/V optimized for high-torque, low-RPM applications on large propellers.
- Wide voltage compatibility from 6S (22.2V) to 12S (44.4V) LiPo batteries for scalable power systems.
- High power output up to 1400W with a maximum continuous current rating of 31.5A.
- Engineered for efficiency with a thrust-to-power ratio of 8.3 g/W to maximize flight time.
- Robust construction with an 8mm shaft diameter and 28-pole design for smooth, reliable operation.
Out of stock
The Pro-Range D8120-100DKV CW brushless motor is designed as a core propulsion component for professional-grade drones requiring substantial lift capacity and operational longevity. Its 100KV winding is specifically calibrated to generate high torque at lower rotational speeds, making it ideal for swinging large-diameter, high-pitch propellers efficiently on multi-cell battery packs.
Built with a focus on thermal management and structural integrity, the motor features a high pole count for smooth rotation and can operate within a wide temperature range. The 8mm hardened steel shaft and robust stator assembly ensure durability under the continuous high loads typical in aerial surveying, cinematography, and cargo delivery UAVs.
Additional Information
| Weight | 0.651 kg |
|---|---|
| Dimensions | 10 × 11 × 10 cm |
