Great Scott Gadgets HackRF One SDR Transceiver 1MHz-6GHz
The Great Scott Gadgets HackRF One is an open-source Software Defined Radio (SDR) transceiver covering 1 MHz to 6 GHz, powered via USB and compatible with GNU Radio, SDR#, and other SDR software for RF development and analysis.
Features
- Wideband RF coverage from 1 MHz up to 6 GHz for comprehensive spectrum analysis and signal generation.
- Half-duplex transceiver with up to 20 MS/s sampling rate for high-fidelity signal capture and transmission.
- Open-source hardware and software, fully supported by the SDR community and major frameworks like GNU Radio.
- USB-powered operation via Hi-Speed USB 2.0, simplifying portable and desktop testing setups.
- Features SMA antenna and clock I/O connectors for flexible external synchronization and antenna integration.
Out of stock
The HackRF One from Great Scott Gadgets is a foundational tool for RF engineers, researchers, and security professionals. Its software-defined architecture allows you to receive, analyze, and transmit a vast array of radio protocols across its 1 MHz to 6 GHz operational window. The platform’s 20 million samples per second capability and 8-bit quadrature sampling provide the resolution needed for detailed signal inspection and modulation experiments.
Designed as a half-duplex transceiver, it switches between transmit and receive modes under software control, with configurable gain and baseband filtering. The unit is fully USB-powered, enabling field-portable operation or integration into lab benches without external power supplies. Its injection-molded enclosure houses the robust RF circuitry, making it suitable for both controlled environments and prototyping work.
Additional Information
| Weight | 0.193 kg |
|---|---|
| Dimensions | 20 × 12 × 4 cm |
