HoneyComm HCBB22 IoT Bluetooth Beacon, iBeacon, IP68, 100m Range

Name: HoneyComm HCBB22 IoT Bluetooth Beacon, iBeacon, IP68, 100m Range
Brand: HoneyComm
SKU: IOWC-0098
Price: 1089.00 INR
Availability: OutOfStock

₹1,089.00 (Inclusive of all taxes)

Out of Stock

The HoneyComm HCBB22 is a professional-grade, IP68-rated Bluetooth Low Energy (BLE 4.2/5.0) beacon designed for long-term, battery-powered IoT deployments, featuring configurable iBeacon parameters via the KTBB Connect mobile app.

Features

5-Year Battery Life: Powered by a CR2477 cell, achieving up to 5 years of operation at a 0dBm transmit power and 1-second broadcast interval.
100-Meter Broadcast Range: Provides a reliable signal coverage of up to 100 meters in open sight for robust asset tracking and proximity detection.
Fully Configurable iBeacon: Customize broadcast name, UUID, Major, Minor, TX power, and interval via the KTBB Connect mobile app for flexible deployment.
IP68 Waterproof & Rugged: Sealed enclosure with an IP68 rating and a wide operating temperature range (-40°C to 85°C) for demanding indoor/outdoor installations.
Connectable & OTA-Capable: The connectable variant supports remote parameter configuration and Over-The-Air (OTA) firmware upgrades for future-proofing deployments.

Out of stock

Get Notified When Available

Description

The HoneyComm HCBB22 is an industrial Bluetooth beacon engineered for persistent, low-maintenance IoT applications. It leverages a low-power Bluetooth SoC to broadcast standard iBeacon/Eddystone frames containing customizable identifiers, RSSI data, and battery level, enabling precise indoor positioning and asset tracking systems.

Its robust design, featuring an IP68 waterproof rating and dual mounting options (3M adhesive or screw), ensures reliable operation in harsh environments from -40°C to 85°C. The beacon’s ultra-low 19µA operating current, combined with a high-capacity CR2477 battery, delivers an exceptional multi-year operational lifespan, minimizing total cost of ownership.

Key Features

Ultra-low power consumption architecture for extended field deployment.
Configurable broadcast parameters (UUID, Major, Minor, TX power, interval) via dedicated mobile app.
Supports both iBeacon and Eddystone protocols for compatibility with major positioning platforms.
IP68-rated enclosure provides complete protection against dust and prolonged water immersion.
Connectable variant enables remote management and firmware updates over Bluetooth (OTA).
Broadcasts critical telemetry including battery level and calibrated RSSI@1m for distance estimation.

Applications

Indoor Positioning & Navigation Systems (IPS)
Asset Tracking & Inventory Management
Proximity Marketing & Information Push in Retail
Museum, Gallery, and Scenic Area Guided Tours
Patrol Check-in & Workforce Management
Smart Building & Facility Management

Technical Specifications

Wireless Protocol	Bluetooth Low Energy (BLE 4.2 / 5.0)
Chipset	Low-Power Bluetooth SoC
Broadcast Range	Up to 100 meters (open sight)
Supply Voltage	3.0 VDC (CR2477 Battery)
Operating Current	~19 µA (typical)
Battery Life	Up to 5 years (0dBm, 1s interval)
Configuration Interface	KTBB Connect Mobile App (Bluetooth)
Enclosure Rating	IP68 Waterproof
Operating Temperature	-40°C to +85°C
Dimensions (L x W)	49 mm x 49 mm
Weight	26 g

Frequently Asked Questions

How do I configure the broadcast parameters of the HCBB22 beacon?

Download the 'KTBB Connect' app on your iOS or Android smartphone. Enable Bluetooth on your phone, power on the beacon, and it should appear in the app's device list. Select it to connect (for connectable variants) and access the configuration menu to set the UUID, Major, Minor, transmit power, broadcast interval, and device name. Changes are written directly to the beacon's memory via BLE.

What is the difference between the connectable and non-connectable HCBB22 variants?

The connectable variant allows a smartphone or gateway to establish a Bluetooth GATT connection for real-time parameter configuration and Over-The-Air (OTA) firmware updates. The non-connectable variant is set once via a proprietary programmer and then only broadcasts its signal; it cannot be reconfigured wirelessly. For field-updatable deployments, the connectable type is recommended.

How is the 5-year battery life calculated, and what factors affect it?

The 5-year estimate is based on using a fresh CR2477 battery, a transmit power of 0dBm, a broadcast interval of 1 second, and an ambient temperature of 25°C. Increasing the transmit power, shortening the broadcast interval, or operating in extreme temperatures will increase current draw and reduce battery lifespan. The beacon's ultra-low ~19µA sleep current between broadcasts is key to longevity.

Can the HCBB22 beacon be used for outdoor installations?

Yes, the HCBB22 is well-suited for outdoor use. Its IP68 rating guarantees protection against dust ingress and continuous immersion in water. The wide operating temperature range of -40°C to 85°C covers most environmental extremes. For mounting, you can use the provided 3M VHB adhesive on clean surfaces or utilize the screw mounting points on the housing for a permanent, secure installation.
