Vector Technics Technics Vector Technics 8008 -110Kv Motor
The Vector Technics Technics Vector Technics 8008 is a high-torque 110KV brushless motor engineered for heavy-lift and agricultural drone platforms, supporting 6S to 12S LiPo/LiHV battery systems (24V-52V) and compatible with propellers up to 28 inches in diameter.
Features
- 110KV rating optimized for high torque and low RPM on large propellers.
- Rated for 6S to 12S LiPo/LiHV operation (24V-52V).
- Delivers up to 666W continuous power (180 seconds) with a 14A continuous current.
- Features dual SKF 619/8-2Z bearings and an 8mm output shaft for robust operation.
- IP45 rated for protection against dust and water ingress in agricultural environments.
Out of stock
The Vector Technics 8008 -110Kv motor is designed for demanding UAV applications requiring sustained power and high torque. Its low KV rating and high torque constant (0.118 Nm/A) enable efficient operation with large-diameter propellers up to 28 inches, making it ideal for heavy-lift cargo drones and precision agriculture sprayer platforms. The motor’s construction prioritizes thermal management and mechanical longevity, with a specified design life of 1000 hours.
Operating within a 44V to 52V (12S LiHV) range, this motor provides a power density of up to 5.2 W/g, balancing performance with a lightweight 210-gram frame. The integrated dual-bearing system and IP45 environmental rating ensure reliable performance in outdoor and dusty conditions, supporting continuous operation at high power levels for extended flight durations.
Additional Information
| Weight | 0.31 kg |
|---|---|
| Dimensions | 11 × 11 × 11 cm |
