Vector Technics Technics Vector Technics 6020 180KV Heavy-Lift Motor - 425g
The Vector Technics Technics Vector Technics 6020 is a 180KV brushless outrunner motor engineered for heavy-lift and agricultural drone platforms, supporting 6S-12S LiPo/LiHV battery systems (44V-52V) and compatible with propellers up to 26 inches in diameter.
Features
- 180KV rating optimized for high-torque, low-RPM heavy-lift applications.
- Supports 6S-12S LiPo/LiHV voltage range (44V-52V) for flexible power system integration.
- Delivers up to 2209W continuous power (for 180 seconds) with a 47A continuous current rating.
- Robust triple-bearing (619/6-2Z) design and IP45 ingress protection for demanding environments.
- Lightweight 425g construction with a power density of 3.53 W/g (rated).
Out of stock
The Vector Technics 6020 180KV motor is designed for professional-grade UAVs requiring sustained high-torque output, such as agricultural sprayers, mapping platforms, and cargo carriers. Its outrunner configuration and low KV value provide efficient power delivery for large-diameter propellers up to 26 inches, maximizing thrust while managing thermal loads across extended flight durations.
Built with a triple-bearing system and an IP45-rated housing, the motor offers enhanced durability against dust and moisture ingress common in field operations. The electrical design is optimized for a 44V to 52V input range, making it compatible with high-capacity 12S LiHV packs for maximum energy density and flight time.
Additional Information
| Weight | 0.48 kg |
|---|---|
| Dimensions | 11 × 11 × 11 cm |
